Hansgrohe 98133000 16x2mm O-Ring
SUMMARY
Hansgrohe 98133000 16x2mm O-Ring Seal for Shower and Bath Fittings
The Hansgrohe 98133000 is a 16 x 2 mm O-ring sealing ring used at designated internal joints within selected Hansgrohe and AXOR shower controls, bath and shower mixers, thermostatic controls and shower fittings. The installation position varies according to the parent product, so the complete product code and construction period should be checked before ordering.
The O-ring creates a watertight seal between mating components. A worn, hardened, flattened, split, twisted or displaced O-ring can allow water to escape around the relevant joint. Do not select this seal from its dimensions alone because other O-ring sizes are used throughout Hansgrohe and AXOR assemblies.
Technical Details
- - Brand: Hansgrohe / AXOR
- - Manufacturer code: 98133000
- - Part type: O-ring sealing ring
- - Internal diameter: 16 mm
- - Cord / cross-section thickness: 2 mm
- - Nominal size: 16 x 2 mm
- - Material: EPDM
- - Hardness: 70 IRHD
- - EAN: 4011097500133
- - Installation position: product-specific
- - Thread and handedness: not applicable
- - Supersession status: no replacement or superseding code confirmed
Confirmed Compatible Models Using 98133000 O-Ring
- - Hansgrohe Raindance Select S 26466000 overhead shower 240 2jet with shower arm - 06/13 to 01/18 and from 02/18
- - Hansgrohe Ceiling Connector E 27467000 100 mm - 10/14 to 11/20 and from 12/20
- - Hansgrohe Raindance E 27376000 overhead shower 360 1jet with 39 cm shower arm
- - Hansgrohe 15760007 ShowerSelect Thermostat Highflow - from 10/18
- - Hansgrohe 15748000 ShowerSelect S mixer for concealed installation for 2 functions - from 05/14
- - Hansgrohe 15734400 ShowerSelect Glass Thermostat Highflow - from 08/16
- - Hansgrohe 15763677 ShowerSelect thermostat for 2 functions - from 10/19
- - Hansgrohe 15743670 ShowerSelect S thermostat for 2 functions - from 06/20
- - Hansgrohe 15745007 ShowerSelect S valve for 3 functions - from 07/18
- - Hansgrohe 36717000 AXOR ShowerSelect valve square for 3 functions - 04/15 to 09/16
- - Hansgrohe 36773000 AXOR ShowerSelect valve Softsquare for 3 functions - 04/15 to 09/16
- - Hansgrohe 36705330 AXOR ShowerSelect thermostat Softsquare for 1 function - from 11/16
- - Hansgrohe 15705000 Ecostat E thermostat for concealed installation - from 05/14
- - Hansgrohe 15790000 Ecostat S thermostat for concealed installation for 2 functions - from 04/19
- - Hansgrohe 15864821 Ecostat single lever shower mixer for concealed installation - from 03/22
- - Hansgrohe 15407000 PuraVida pressure balance single lever shower mixer - 01/12 to 12/16
- - Hansgrohe 15677000 PuraVida single lever shower mixer Highflow - 01/15 to 12/16
- - Hansgrohe 15665400 PuraVida single lever shower mixer - 07/09 to 12/16
- - Hansgrohe 15665407 PuraVida single lever shower mixer - from 01/18
- - Hansgrohe 15665000 PuraVida single lever shower mixer - 07/09 to 12/16
- - Hansgrohe 15445400 PuraVida single lever bath mixer - 01/17 to 06/22
- - Hansgrohe 15403000 Metris S pressure balance single lever shower mixer - 01/12 to 12/17
- - Hansgrohe 15404000 Metris Classic pressure balance shower mixer - 02/12 to 12/16
- - Hansgrohe 31487000 Metris single lever bath mixer with integrated backflow protection - from 01/16
- - Hansgrohe 31685000 Metris concealed shower mixer - 01/17 to 09/19
- - Hansgrohe 31685007 Metris concealed shower mixer - from 10/19
- - Hansgrohe 31676000 Metris Classic concealed shower mixer - 04/09 to 12/16
- - Hansgrohe 31763000 Focus S concealed shower mixer - 01/08 to 12/16
- - Hansgrohe 31965000 Focus concealed shower mixer - 01/17 to 09/19
- - Hansgrohe 14165000 Talis Classic concealed shower mixer - 01/17 to 09/19
- - Hansgrohe 71454000 Vernis Blend single lever bath mixer with 2 flow rates - from 01/21
- - Hansgrohe 71440000 Vernis Blend single lever bath mixer - from 01/21
- - Hansgrohe 71646000 Vernis Blend single lever shower mixer with 2 flow rates - from 01/21
- - Hansgrohe 71640000 Vernis Blend exposed shower mixer - from 01/21
- - Hansgrohe 71640007 Vernis Blend exposed shower mixer - from 04/20
- - Hansgrohe 71640670 Vernis Blend exposed shower mixer Matt Black - from 04/21
- - Hansgrohe 71667670 Vernis Blend concealed shower mixer Matt Black - from 06/22
- - Hansgrohe 71650000 Vernis Shape exposed shower mixer - from 05/24
- - Hansgrohe 11731000 AXOR Urquiola Thermostat Highflow - from 02/12
- - Hansgrohe 10416000 AXOR Starck concealed single lever bath mixer with pin handle - from 01/16
- - Hansgrohe 12416000 AXOR Starck Organic concealed single lever bath mixer - 02/13 to 12/16
- - Hansgrohe 16551820 AXOR Montreux exposed 2-handle bath mixer - from 10/16
- - Hansgrohe 17470810 AXOR Carlton rim-mounted 2-handle bath mixer DN15 - 07/00 to 10/09
- - Hansgrohe 36715260 AXOR ShowerSolutions thermostat square for 2 functions - 11/16 to 12/19
Before Ordering
- - Confirm the complete Hansgrohe or AXOR product code and construction period against the relevant spare-parts diagram
- - Compare the removed O-ring and its installation position rather than relying on the 16 x 2 mm dimensions alone
- - Inspect the sealing groove and adjoining surfaces for scale, debris or damage before fitting the new seal
- - Apply a suitable silicone lubricant where required and avoid twisting, stretching or pinching the O-ring during installation
Not sure this is the right part? Use the Di Vapor Part Identification Service and we can help identify it.
