Hansgrohe 96623000 Cartridge - HG-96623000
Send a photo of your item and we'll help confirm it.
Summary
Hansgrohe 96623000 3/4 Inch On-Off Flow Shower Cartridge
The Hansgrohe 96623000 is a 3/4 inch ceramic on-off flow cartridge used inside selected concealed shower valve controls. The cartridge operates the shut-off function by opening and closing the water flow and is separate from the outlet selector or diverter cartridge.
A worn flow cartridge can cause water to continue dripping from the shower head or outlet after the control is turned off. Other possible symptoms include stiff control movement, reduced flow and failure to shut the water off completely.
Technical Details
| Manufacturer part code | 96623000. |
|---|---|
| Part type | ceramic shut-off unit and on-off flow cartridge. |
| Nominal size | 3/4 inch. |
| Total height | 64mm. |
| Opening direction | anti-clockwise to open. |
| Function | controls the water flow on and off. |
Confirmed Application
Important Note: Hansgrohe 96623000 is documented for earlier versions of valve 31958000. Later spare-parts information shows shut-off unit 98536000 in this position. Compare the code on the removed cartridge, the overall height, the stem shape and the valve construction period before ordering.
- Hansgrohe Metris iControl E shut-off and diverter valve 31958000 - construction period 06/11 to 04/19.
Installation and Before Ordering Checks
- Isolate the hot and cold water supplies before dismantling the valve.
- Apply a small amount of suitable silicone grease to the cartridge O-rings and bottom seal before installation.
- Do not identify the cartridge from the 3/4 inch size or 64mm height alone.
- Check that the opening direction and control stem match the removed cartridge.
- Contact Di Vapor with photographs and measurements if the cartridge code cannot be read.
