Grohe 47439000 Compact Thermostatic Cartridge 1/2" for Grohtherm, Grohmaster, Allure, THM and Rainshower Valves (47.439)
Send a photo of your item and we'll help confirm it.
Summary
The 47439000 (47.439) cartridge is used in the following Grohe shower valves:
- Grohe 1/2” Grohtherm 3000 Cosmopolitan 34275 Thermostatic shower mixer valve
- Grohe 1/2” Grohtherm 2000 Special 34205 Thermostatic shower mixer valve
- Grohe 1/2” Concealed body for THM 34212 Thermostat bath mixer valve
- Grohe 1/2” Grohtherm 2000 34174 Thermostatic bath/shower mixer valve
- Grohe 1/2” Concealed body for THM 34211 Thermostat shower mixer
- Grohe 1/2” Grohmaster 34154 Grohtherm 1000
- Grohe 1/2” Grohtherm 2000 Special 34254 Thermostatic bath/shower mixer
- Grohe 1/2” Grohtherm 1000 34268 Thermostatic shower mixer valve
- Grohe 1/2” Grohtherm 1000 34215 Thermostatic bath/shower mixer
- Grohe 1/2” Grohtherm 3000 Cosmopolitan 34276 Thermostatic bath/shower mixer
- Grohe 1/2” Grohmaster 34181 Grohtherm 3000
- Grohe 1/2” Grohtherm 1000 34286 Thermostatic shower mixer
- Grohe 1/2” Grohtherm 1000 34146 Thermostatic shower mixer
- Grohe 1/2” Rainshower 27374 Shower system for wall mounting
- Grohe 1/2” Grohtherm 1000 34065 Thermostatic shower mixer
- Grohe 1/2” Grohtherm 1000 34161 Thermostatic shower mixer valve
- Grohe 1/2” Grohtherm 3000 Cosmopolitan 34274 Thermostatic shower mixer
- Grohe 1/2” Grohtherm 2000 Special 34202 Thermostatic bath/shower mixer
- Grohe 1/2” Grohtherm 2000 Special 34255 Thermostatic shower mixer valve
- Grohe 1/2” Grohtherm 3000 34188 Thermostatic bath/shower mixer
- Grohe 1/2” Rainshower 27174 Shower system for wall mounting PARENT-487
- Grohe 1/2” Grohtherm 3000 Cosmopolitan 34277 Thermostatic bath/shower mixer
- Grohe 1/2” Allure 34236 Thermostatic shower mixer valve
- Grohe 1/2” Concealed body for THM 34213 Thermostat for bath/shower mixer
- Grohe 1/2” Grohtherm 3000 34193 Grohtherm 3000
- Grohe 1/2” Grohtherm 1000 34155 Thermostatic bath/shower mixer
- Grohe 1/2” Grohtherm 3000 Cosmopolitan 34278 Thermostatic shower mixer
- Grohe 1/2” Grohmaster 34162 Grohtherm 1000
- Grohe 1/2” Grohtherm 3000 34185 Thermostatic bath/shower mixer valve
- Grohe 1/2” Grohtherm 1000 34156 Thermostatic bath/shower mixer
- Grohe 1/2” Grohtherm 3000 34179 Thermostatic shower mixer
- Grohe 1/2” Grohtherm 1000 34143 Thermostatic shower mixer valve
- Grohe 1/2” Grohtherm 1000 34321 Thermostatic shower mixer valve
- Grohe 1/2” Grohtherm 1000 34323 Thermostatic bath/shower mixer
The 47439000 thermostatic cartridge is a genuine Grohe product and is made from a plastic polymer.
| Manufacturer | Grohe |
|---|---|
| Spare Part | Compact Thermostatic Cartridge 47439000 |
| Installation | Push Fit |
| Material | Plastic Polymer, Chrome |
| Number of External O-Ring | 4 |
| Number of Guazing | 2 |
Grohe 47439000 measurement:
Length: 12.7 millimeters.
*It is a replacement part for various Grohe 1/2 inch shower mixer valves where the thread measurement is approximately 21 millimeters.
Replacing a Grohe 47439000 Compact Cartridge on a Shower Mixer Valve
To access the Grohe 47439000 compact thermostatic cartridge in the Grohe THM 34213 shower mixer, the handle and the retaining ring must be removed. Then, after applying a small amount of silicone grease on the four outer o-rings of the cartridge, it can be installed in the valve seat.
To retrieve the cartridge on an exposed shower valve such as the Grohtherm 2000 Special 34202, remove the right side handle holding the thermostatic cartridge. Unfasten the retaining nut and extract the cartridge. Silicone lubricant must be applied to ensure the cartridge will seat right as you install it in the valve.
Need other Grohe spares?
-We provide a wide range of Grohe spare Parts.
The Grohe 47439000 Compact Thermostatic Cartridge made by Grohe is eligible for same day delivery, when purchased before 3:00 PM from Monday to Friday.
Other Cartridge-Related Information:
A thermostatic cartridge can last when water conditions are good. The higher the level of water hardness the more its lifespan shrinks. This is due to the accruing of dregs around the barrel and the gauzing of the cartridge which will create a bottleneck and, thus, inhibit the movement of water.
Also, cracks in the cartridge can develop as a consequence of constant use as hot and cold water pass through it.
