Grohe 1007500M Handle Cover Caps

SUMMARY

GROHE 1007500M Grohtherm 2000 Shower and Bath Mixer Handle Cover Caps - Pair

GROHE 1007500M is a pair of handle cover caps for the Grohtherm 2000 thermostatic shower mixers, bath/shower mixers and concealed controls listed below.

The caps cover the handle fixing screws and finish the outside of the controls. They are used on the specified temperature and flow-control handle assemblies. Renewing a missing or damaged cap restores the appearance of an otherwise serviceable handle. These are cover caps, not complete handles, thermostatic cartridges or temperature safety buttons.

Technical Details

- - Product code: 1007500M

- - Part type: Handle fixing-screw cover caps

- - Quantity: Two caps, supplied as a pair

- - Fitting position: Over the fixing screw on the specified control handles

- - Exploded-diagram reference: 10 075

Before You Order

Check the complete mixer or trim-set code, the existing handle and its cap opening. The Grohtherm 2000 name covers different designs and generations, so the range name or a similar appearance does not establish fitment. Check whether only the cap is damaged or whether the handle and its fixing also need attention.

Confirmed Models Using 1007500M

- - GROHE 34169000 Grohtherm 2000 Exposed Thermostatic Shower Mixer

- - GROHE 34174000 Grohtherm 2000 Thermostatic Bath/Shower Mixer

- - GROHE 34216000 Grohtherm Automatic 2000 Thermostatic Shower Mixer

- - GROHE 19354000 Grohtherm 2000 Concealed Thermostatic Shower Mixer Trim

- - GROHE 19355000 / 19355 000 Grohtherm 2000 Concealed Thermostat with Integrated Two-Way Diverter

- - GROHE 19242000 Grohtherm 2000 Concealed Thermostatic Bath/Shower Mixer Trim

- - GROHE 34235000 Grohtherm 2000 3/4-Inch Thermostatic Shower Mixer

- - GROHE 19352000 Grohtherm 2000 Central Thermostat for Bath and/or Shower

- - GROHE 34221 / 34221000 Grohmaster Grohtherm 2000 EV Shower

- - GROHE 34218 / 34218000 Grohmaster Grohtherm 2000 BIV Shower

- - GROHE 34 175 Grohtherm 2000 Thermostatic Bath/Shower Mixer

- - GROHE 34 176 Grohtherm 2000 Thermostatic Bath/Shower Mixer

Related Spares You May Need

These are separate, model-dependent service parts for the listed mixer assemblies. They are not all required when renewing the cover caps. For concealed installations, identify the valve body as well as the visible trim. A shared handle-cap code does not make different internal cartridges, adapters or retaining rings interchangeable.

Handle and Trim Components

- - GROHE 47744000 flow-control handle, for the specified flow and diverter control arrangements

- - GROHE 47286000 temperature-control handle, for the specified extension-set arrangements, not a general substitute for every original handle

- - GROHE 47749000 chrome cover plate, for the specified two-handle concealed controls, not the single-handle 19352000 trim

- - GROHE 10089000 stop ring, for the flow/diverter controls on 19242000 and 19355000

- - GROHE 47780000 Rapido T extension kit, an extension option for the specified 19352000 installation

Flow and Diverter Service Parts

- - GROHE 45346000 half-turn flow cartridge, for 34169000 and the specified 19354000 valve arrangement

- - GROHE 07146000 on/off headpart, for 34216000 and 34221

- - GROHE 07025000 3/4-inch on/off headpart, for 34218 and 34235000

- - GROHE 47364000 Aquadimmer flow and diverter cartridge, for the specified concealed-body arrangements behind 19355000 and 19242000

- - GROHE 12701001 Aquadimmer waterway and cartridge attachments, for the specified 19355000 Aquadimmer arrangement

- - GROHE 12433000 Aquadimmer cartridge, for the 34174000, 34 175 and 34 176 bath/shower mixer arrangements

- - GROHE 47751000 Aquadimmer waterway adapter, used with the 12433000 cartridge in the specified bath/shower mixers

- - GROHE 49348000 Aquadimmer cartridge and adapter assembly, combines 12433000 and 47751000, avoiding separate orders for those components when the complete assembly is required

- - GROHE 0305600M Aquadimmer O-ring, for the specified 12433000 cartridge arrangement

Temperature-Control Service Parts

- - GROHE 47439000 thermostatic cartridge, for 34169000, 34174000 and the specified concealed body behind 19242000

- - GROHE 47175000 reverse thermostatic cartridge, for the specified reversed hot and cold supply arrangements, including 34174000

- - GROHE 47743000 retaining ring, for the specified temperature-cartridge arrangement in 34169000 and 34174000

- - GROHE 47483000 Turbostat thermostatic cartridge, for 34216000, 34221, 34218, 34235000 and the specified concealed valve bodies

- - GROHE 47186000 reverse thermostatic cartridge, for the specified reversed-supply concealed-body arrangements, including those behind 19354000 and 19355000

- - GROHE 47765000 retaining ring, for the specified 47483000 cartridge arrangements, including 34221 and 34218

Other Valve Service Parts

- - GROHE 08565000 non-return valve, for 34169000, 34174000, 34216000 and 34221

- - GROHE 47753000 non-return valve, for the specified 34218 and 34235000 arrangements

- - GROHE 0392400M pack of 10 O-rings, listed for the 34221 valve assembly

- - GROHE 19332000 34mm hex socket box spanner, for the specified internal valve servicing operations, not required simply to fit a cover cap

Fitting and Fault Identification

Follow the instructions for the exact mixer. The handle and its fixing screw are fitted before the cover cap. A new cap restores the finished appearance, but it does not repair an internal leak or faulty temperature control. Persistent dripping from the shower head or spout when the mixer is switched off requires investigation of the relevant valve components, rather than the cover cap.

For help identifying the correct part, contact us with the full model number and clear photographs of the complete mixer, the handle and the cap opening.
