GROHE 47167000 Stop Ring Auto 2000 Adapter for 4745000 Thermostatic Cartridges
Send a photo of your item and we'll help confirm it.
Summary
GROHE 47167000 Stop Ring Auto 2000 Adapter for 4745000 Thermostatic Cartridges
This part connects onto the top of the 4745000 cartridge (i.e. the part which connects the cartridge to the temperature control handle).
This adapter is used in the following shower mixer valves:
- Grohe Grohterm 3000 19 665 Oval Concealed Thermostatic Shower Mixer
- Grohe 34 650 Automatic 2000 Mixer (Basic/Clova)
- Grohe Concealed body for THM 34959 Thermostat mixer 3/4"" concealed body
- Grohe Automatic 2000 34954 Thermostat mixer 1/2"
- Grohe Grohterm 1000 Oval Concealed Thermostatic Shower Mixer
- Grohe Grohtherm 3000 19 663 Oval Concealed Thermostatic Shower Mixer
- Grohe Grohmaster 34 025 Grohtherm 1000 Ev
- Grohe Automatic 2000 34953 Thermostat mixer 1/2" concealed body
- Grohe Aquatower 3000 Top 4 Shower System 3/4 27 202
- Grohe Sentosa Mixing Valve
- Grohe Grohtherm 3000 (34367) Thermostatic bath/shower Mixer
- Grohe 34 357 Automatic 2000 Bath Mixer (Basic/Clova)
GROHE 47167000 is a stop ring and regulating nut assembly for the temperature-control side of selected thermostatic shower and bath/shower mixer valves. It fits between the thermoelement and the temperature-control handle, providing the adjustment and stop interface used to set the handle position.
This is not a thermostatic cartridge. Correct positioning of the stop ring and regulating nut is important because the assembly establishes the relationship between the thermoelement and the calibrated temperature-control handle.
Technical Details
| Part type | stop ring and regulating nut assembly |
|---|---|
| Application | temperature-control side of a thermostatic mixer valve |
| Position | between the thermoelement and temperature-control handle |
| Function | provides calibration adjustment and the handle travel and safety-stop interface |
| Associated standard thermoelement code | 47450000 |
| Service calibration reference | 38 degrees C after thermoelement servicing |
| Supply orientation | determined by the fitted thermoelement rather than the stop ring |
Confirmed Compatible Models
- GROHE 34328000 Grohtherm Auto 1000 Shower
- GROHE 34334000 Grohtherm Auto 1000 Bar Mixer Shower
- GROHE 34336000 Grohtherm 1000 Thermostatic Bath Mixer
- GROHE 34624000 Grohtherm 1000 Thermostatic Shower
- GROHE 34646000 Grohtherm Auto 1000 Bar Mixer Shower
- GROHE 34310000 Grohtherm Auto 2000 Shower
- GROHE 34650000 Automatic 2000 Thermostatic Shower Mixer
- GROHE 19605000 Grohtherm Automatic 2000 Shower
- GROHE 19657000 Grohtherm Auto 2000 Shower Valve
- GROHE 34954000 Automatic 2000 Thermostat Mixer 1/2 Inch
- GROHE 34963000 Mixer Valve Shower
- GROHE 34964000 Mixer Valve
- GROHE 34966000 Mixer Valve
- GROHE 34968000 Shower Mixer Valve
- GROHE 34367000 Grohtherm 3000 Thermostatic Bath/Shower Mixer
- GROHE 34479000 Grohtherm Auto 3000 Bath/Shower Mixer
- GROHE 19663000 Grohtherm 3000 Oval Concealed Thermostatic Shower Mixer
- GROHE 19665000 Grohtherm 3000 Oval Concealed Thermostatic Shower Mixer
- GROHE 19682000 Europlus Mixer Shower with Flow Control
- GROHE 34551000 Sentosa Thermostatic Bath/Shower Mixer
- GROHE 34001000 Europlus Thermostat Bath/Shower Mixer
Before Ordering
Check the complete mixer code and the thermoelement already fitted before ordering. Depending on the valve configuration, GROHE 47167000 is used with standard-supply or reverse-supply thermoelements in 1/2-inch or 3/4-inch versions. Do not select this part by diameter or appearance alone.
Installation Note
Isolate the hot and cold water supplies before dismantling the valve. Remove the temperature-control handle, followed by the regulating nut and stop ring. After servicing the thermoelement, recalibrate the mixed-water temperature to 38 degrees C before securing the handle in the correct position.
Related Spares You May Need
- GROHE 47450000 1/2 Inch Thermoelement
- GROHE 47282000 1/2 Inch Reverse-Supply Thermoelement
- GROHE 47310000 3/4 Inch Thermoelement
- GROHE 47379000 3/4 Inch Reverse-Supply Thermoelement
- GROHE 47255000 Temperature Control Handle
- GROHE 47352000 Temperature Control Handle
- GROHE 47440IP0 Temperature Control Handle
- TACSIL 3g WRAS Approved Silicone Grease
- Cartridge Screw M4 - 10mm Long Thread
