Grohe 47477000 Non-Return Valve

SUMMARY

GROHE 47477000 Non-Return Valve for Thermostatic Mixer Valves

GROHE 47477000 is a non-return valve used inside selected GROHE thermostatic mixer shower and bath/shower valve assemblies. It allows water to pass in the intended direction while helping to prevent reverse flow through the mixer, supporting correct hydraulic operation of the valve.

The valve is an internal service component rather than an external control. Older GROHE service documentation may identify the same part using the shortened reference 47 477.

Technical Details

- - Part code: 47477000

- - Part type: non-return valve / check valve

- - Fitting thread diameter: 31.8mm

- - Plastic NRV diameter: 25mm

- - Historical service notation: 47 477

- - Function: permits flow in the intended direction and helps prevent reverse flow

Confirmed Compatible Models

- - GROHE 34 908 Grohtherm 3/4 Inch Thermostat Rough-In Valve

- - GROHE 34 226 Grohmaster Automatic 2000 3/4 Inch Shower

- - GROHE 19135 / 19135000 Atrio Ypsilon Shower

- - GROHE 19136 / 19136000 Atrio Jota Thermostat Bath Shower Mixer

- - GROHE 19657000 / 19657 000 Grohtherm Auto 2000 Shower Valve

- - GROHE 34103000 / 34103 000 Mixer Valve Shower

- - GROHE 34963000 / 34963 000 Mixer Valve Shower

- - GROHE 34964000 / 34964 000 Mixer Valve

- - GROHE 19060000 GEN1 Tenso Thermostatic Bath / Shower Mixer Trim 2001-2007

Before You Order

Confirm the valve model and existing part reference before ordering. Do not select this non-return valve from the 31.8mm fitting thread diameter or 25mm plastic NRV diameter alone, because these measurements do not establish fitment.

Related Spares You May Need

- - GROHE Atrio 06676000 Temperature Control Handle 08.945 ABS

- - GROHE 08943000 Atrio Snap Insert Spline Adapter White and Grey

- - GROHE 07025000 3/4 Inch Shower Cartridge Valve On/Off

- - GROHE 45885000 Ceramic Disc Flow Cartridge 45885 000

- - GROHE 47167000 Stop Ring Auto 2000 Adapter for 4745000 Thermostatic Cartridges

- - GROHE 47187000 Flow Control Knob for Auto 2000 Shower Valves

- - GROHE 47220000 3/4 Inch Thermostatic Cartridge with Non-Rising Spindle

- - GROHE 47255000 Temperature Control Handle

- - GROHE 47262000 Aquadimmer Flow Cartridge On/Off

- - GROHE Atrio 47289000 Temperature Control Handle

- - GROHE 47300000 Stop Ring F Atrio 1944/5/6 Adapter for 47217000 Thermostatic Cartridge

- - GROHE 47310000 Thermoelement 3/4 Inch Thermostatic Cartridge

- - GROHE 47324000 Flow Control Lever Handle

- - GROHE 47336000 Cover Plate Fixing Set

- - GROHE 47379000 Thermoelement 3/4 Inch Thermostatic Cartridge Reverse Supplies

- - GROHE 47582000 Chrome 3/4 Inch Thermostatic Cartridge

- - GROHE 47658000 Thermostatic Cartridge 3/4 Inch Reverse Supplies / Non-Rising Spindle
