Grohe 07025000 3/​4 Shower Cartridge Valve (On/​Off) - Compatible Spare

SUMMARY

07025000-CS 3/4 Inch Shower On/Off Flow Cartridge Replacement for GROHE 07025000

The 07025000-CS is a replacement on/off flow-control cartridge for the GROHE 07025000 valve used in selected shower mixers, bath/shower mixers and concealed valves. This listing is for replacement spare 07025000-CS, distinct from the separately listed original-reference part GR-07025000.

The cartridge controls the opening and closing of the water supply through the flow-control assembly. In thermostatic mixers, it performs a different function from the thermostatic cartridge that regulates water temperature. It is also separate from a bath-to-shower diverter, which selects the outlet.

Technical Details

- - Part Number: 07025000-CS

- - Original valve reference: 07025000

- - Part type: on/off flow-control cartridge

- - Nominal valve size: 3/4 inch

- - Application: replacement for the specified 07025000 screw-down flow-valve arrangement in shower mixers, bath/shower mixers and concealed valves

Before Ordering

Identify the original flow-valve reference and exact mixer model before ordering. Compare the existing cartridge's shape, threaded connection and handle engagement with the product photographs. The nominal 3/4-inch size alone does not establish fitment, and a shared Grohtherm or Automatic 2000 range name is not sufficient to identify the correct valve.

For 19657000 and 34963000 installations, check whether the existing flow valve is 07025000 or the separately specified ceramic valve 45885000. Do not assume that these different valve references are interchangeable.

Confirmed Compatible Models

The following applications use the original 07025000 flow valve. Select 07025000-CS only where that original valve reference and the installed arrangement have been identified.

- - GROHE 34235 / 34235000 Grohtherm 2000 Thermostatic Shower Mixer 3/4 Inch Components

- - GROHE 34218 / 34218000 Grohmaster Grohtherm 2000 Built-In Shower Components

- - GROHE 34 226 Grohmaster Automatic 2000 3/4 Inch Built-In Shower

- - GROHE 19657000 / 19657 000 Grohtherm Auto 2000 Shower Valve Components, where fitted with the 07025000 flow valve

- - GROHE 34963000 / 34963 000 Mixer Valve Components, where fitted with the 07025000 flow valve

- - GROHE 34448000 GEN1 Grohtherm 1000 Cosmopolitan Thermostatic Bath/Shower Mixer Components, 2011 to 2018

- - GROHE 34519000 Grohtherm 1000 Cosmopolitan Thermostatic Bath/Shower Mixer 1/2 Inch Components

- - GROHE 34449000 Grohtherm 1000 Cosmopolitan Thermostatic Bath/Shower Mixer 3/4 Inch Components

- - GROHE 34 473 Grohtherm 1000 Cosmopolitan Thermostatic Bath/Shower Mixer

- - GROHE 29802000 Concealed Valve 3/4 Inch Components

- - GROHE 29803000 Concealed Valve 3/4 Inch Bottom Part Components

Troubleshooting and Fitting

Symptom: water continues dripping from the shower head or spout after the control is turned off. Likely cause: the flow valve is not sealing correctly; the condition of the valve seat should also be checked. Solution: identify the installed flow valve, inspect the sealing arrangement and replace the faulty component as appropriate. A new cartridge will not repair a damaged valve-body seat.

Isolate the water supply before removing the existing cartridge. Follow the servicing instructions for the exact mixer, check the seating and threads, and test for leaks and correct shut-off after reassembly. A temperature-control fault requires separate diagnosis rather than automatically replacing the on/off valve.

Related Spares You May Need

These are separate service parts for the specific mixer arrangements listed above, not a common service kit for every application. Select additional parts against the exact model and installed components. Sharing the 07025000 flow valve does not establish that two mixers use the same thermostatic cartridge, handles or non-return valves.

- - GROHE 07025000 Original-Reference On/Off Flow Cartridge - GR-07025000, a separate alternative to 07025000-CS rather than an additional component required alongside it

- - GROHE 47744000 Flow-Control Handle, for the specified Grohtherm 2000 34235 and Grohmaster 34218 arrangements

- - GROHE 47187000 Automatic 2000 Flow-Control Knob, for the relevant Automatic 2000 control arrangement

- - GROHE 45186000 Handle-Fixing Set, associated with the flow-control knob in the 34 226 arrangement

- - GROHE 1007500M Handle Cover Caps, for the specified Grohtherm 2000 controls

- - GROHE 42T8M44 Pair of Grohtherm 2000 Handle Caps, to be selected against the existing handle-cap arrangement

- - GROHE 47749000 Grohtherm 2000 Chrome Cover Plate, external trim for the relevant concealed mixer arrangement

- - GROHE 47336000 Cover-Plate Fixing Set, for the specified Automatic 2000 cover-plate arrangement

- - GROHE 47483000 Thermostatic Cartridge, a separate temperature-control component for the mixers that specify this thermostat

- - GROHE 47310000 Thermostatic Cartridge, for the relevant older Automatic 2000 temperature-control arrangement

- - GROHE 47379000 Reverse-Supply Thermostatic Cartridge, only for the corresponding reverse-supply installation

- - GROHE 47765000 Thermostatic Cartridge Retaining Ring, not the retaining nut for the on/off flow valve

- - GROHE 47167000 Temperature-Control Stop Ring and Adapter, for the relevant Automatic 2000 control assembly

- - GROHE 47255000 Temperature-Control Handle, separate from the on/off flow-control knob

- - GROHE 47753000 Non-Return Valve, specified for the 34235 and 34218 mixer arrangements

- - GROHE 47477000 Non-Return Valve, for the relevant older Automatic 2000 installation

- - GROHE 08565000 Non-Return Valve, for the specified Grohtherm 1000 Cosmopolitan bath/shower mixer arrangements

- - GROHE 47906000 Bath-to-Shower Diverter, a separate outlet-selection component in the relevant Cosmopolitan mixers

- - GROHE 47908000 Outlet Flow Straightener, a spout outlet component rather than an on/off cartridge

- - GROHE 18121000 Pillar Unions, for the relevant bath/shower mixer installation

- - GROHE 19332000 34mm Hex Socket Box Spanner, for servicing the specified thermostatic retaining assembly, not identified as the removal tool for this flow cartridge

- - TACSIL 3g Cartridge Silicone Grease, where specified for seal lubrication during servicing

Help Identifying Your Valve

Unsure which flow cartridge is installed? Use the Di Vapor part-identification service and provide the mixer model, photographs of the controls and clear photographs of the removed cartridge, including its threaded section and spindle.
