Grohe 08943000 Atrio Snap Insert Spline Adapter (White & Grey)
Send a photo of your item and we'll help confirm it.
Summary
GROHE 08943000 Atrio Snap Insert Spline Adapter for Control Handles White and Grey
The GROHE 08943000 is a snap insert and spline adapter used within selected GROHE Atrio and related control-handle assemblies. The part is a white and grey Atrio snap insert spline adapter. It is a handle-related service component rather than the thermostatic, flow or pressure-balance cartridge itself.
In GROHE exploded spare-parts layouts, 08943000 is shown as sub-item 1.1 beneath the relevant control handle. It is intended to sit within the handle assembly, so the GROHE model code and handle arrangement should be checked before ordering rather than identifying the part by appearance alone.
Technical Details
| Part code | 08943000 |
|---|---|
| Component type | Snap insert / spline adapter |
| Colour | White and grey |
| Exploded-diagram position | Commonly shown as item 1.1 beneath the relevant control handle |
| Application | Internal handle service component used in selected thermostatic and pressure-balance control assemblies |
Confirmed Compatible Models
- GROHE 34010000 Atrio Thermostat Shower Mixer
- GROHE 34011000 Atrio Thermostatic Shower
- GROHE 34061000 Atrio Thermostat Bath/Shower Mixer
- GROHE 34062000 Atrio Thermostatic Bath Shower Mixer
- GROHE 19135000 Atrio Ypsilon
- GROHE 19136000 Atrio Jota Thermostat Bath Shower Mixer
- GROHE 19141000 Atrio 4-Hole Bath Combination Trim Set
- GROHE 19142000 Atrio 4-Hole Bath/Shower Combination
- GROHE 19144000 Atrio Ypsilon Thermo Shower Valve Trimset
- GROHE 19145000 Atrio Thermostat Shower Mixer
- GROHE 19147000 Atrio Central Thermostat Mixer
- GROHE 19148000 Atrio Central Thermostatic Mixer
- GROHE 19150000 Tenso Pressure Balance Valve Trimset
- GROHE 19169000 Atrio Central Thermostatic Mixer
- GROHE 19392000 Atrio Central Thermostatic Mixer
- GROHE 19394000 Atrio Thermostatic Shower Mixer
- GROHE 19395000 Atrio Thermostat with Integrated 2-Way Diverter
- GROHE 19396000 Atrio Trim for Thermostatic Shower Valve
- GROHE 19398000 Atrio Thermostatic Shower Mixer
- GROHE 19399000 Atrio Thermostat with Integrated 2-Way Diverter
- GROHE 19491000 Pressure Balance Valve Trim with Diverter
- GROHE 19491EN0 Pressure Balance Valve Trim with Diverter
- GROHE 19492000 Atrio Pressure Balance Valve Trim with Diverter
- GROHE 19492BE0 Atrio Pressure Balance Valve Trim with Diverter
- GROHE 19492EN0 Atrio Pressure Balance Valve Trim with Diverter
- GROHE 19493000 Tenso Pressure Balance Valve Trim
- GROHE 19493EN0 Tenso Pressure Balance Valve Trim
Before Ordering
Check the exact GROHE mixer or trim code and the handle arrangement before ordering. The 08943000 should not be selected solely from its appearance or from a partial handle measurement.
