Grohe 47220000 3/4 Inch Thermostatic Cartridge with Non-Rising Spindle for Aquatower 3000 Valves
SUMMARY
GROHE 47220000 is a 3/4 inch thermostatic wax thermo-element cartridge with a non-rising spindle, used to regulate mixed-water temperature in selected GROHE Aquatower 3000, Atrio, Tenso and concealed thermostatic mixer installations.
The wax thermo-element responds to changes in water temperature and adjusts the hot and cold water mix through the valve. When servicing these installations, checking the surrounding Grohe spare parts can also help identify worn control, flow and sealing components that may affect operation.
Technical Details
- - Part code: 47220000
- - Part type: thermostatic wax thermo-element cartridge
- - Nominal size: 3/4 inch
- - Spindle type: non-rising
- - Approximate overall length: 104.64mm
- - Approximate widest diameter: 39.82mm
- - O-rings on cartridge: 4
- - Spline tiers: 1
- - Manufacturer-listed service O-ring 0120600M: 26mm x 2mm
- - Manufacturer-listed service O-ring 0268000M: 32mm x 2.5mm
- - Manufacturer-listed stop ring and regulating nut assembly: 47300000
- - Manufacturer-listed fixing clamp: 0574400M
Confirmed Compatible Models
Grohe 47220000 thermostatic cartridge (3/4" inch) with non-rising spindle for Aquatower 3000 valves used on the following Grohe models:
- - GROHE 27027 / 27027000 Aquatower 3000 Dual Shower System 3/4 Inch
- - GROHE 27026 / 27 026 / 27026000 Aquatower 3000 Dual Shower System
- - GROHE 27203 / 27203000 Aquatower 3000 Top 4 Shower System 3/4 Inch
- - GROHE 27200 Aquatower 3000 Shower System
- - GROHE 27202 / 27 202 / 27202000 Aquatower 3000 Top 4 Shower System 3/4 Inch
- - GROHE 27201 Aquatower 3000 Shower System
- - GROHE 19135 / 19135000 Atrio Ypsilon Shower
- - GROHE 19136 / 19136000 Atrio Jota Thermostat Bath Shower Mixer
- - GROHE 34103000 / 34103 000 Mixer Valve Shower
- - GROHE 34086000 4-Hole Bath Shower Combination Concealed Body
- - GROHE 19141000 Atrio 4-Hole Bath Combination Trim Set
- - GROHE 19142000 Atrio 4-Hole Bath Shower Combination
- - GROHE 19142BE0 Atrio 4-Hole Bath Combination
- - GROHE 19060000 GEN1 Tenso Thermostatic Bath Shower Mixer Trim 2001-2007
- - GROHE Chiara 19 162 with concealed body 34 086
Before You Order Check
- - Confirm the original cartridge or GROHE service documentation identifies 47220000 or historic notation 47 220
- - Check the exact shower, tap or concealed mixer model because similar GROHE thermostatic cartridges are available for different valve bodies
- - Do not select the cartridge from diameter or overall length alone
- - Check the hot and cold supply orientation before ordering; installations with reversed hot and cold supplies use GROHE 47658000 rather than standard 47220000
Installation Note
Isolate the hot and cold water supplies before removing the cartridge. Clean the cartridge chamber and sealing surfaces, lightly lubricate suitable O-rings with silicone grease, and recalibrate the thermostatic control after replacement. Do not force the cartridge into the valve body if it does not seat correctly.
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- - GROHE Atrio 47680000 Control Handle
- - GROHE Atrio 06676000 Temperature Control Handle 08.945 ABS
- - GROHE 47300000 Stop Ring and Regulating Nut
- - GROHE 47542IP0 Flow Diverter Control Handle for Aquatower
- - GROHE 47442IP0 Grohtherm 3000 Flow Control Handle
- - GROHE 45885000 Ceramic Disc Flow Cartridge
- - GROHE 47364000 Aquadimmer Flow Cartridge
- - GROHE 08565000 Non-Return Valve
- - GROHE 0305600M O-Ring for Aquadimmer Cartridge
- - GROHE 08943000 Atrio Snap Insert Spline Adapter
- - GROHE 47262000 Aquadimmer Flow Cartridge
- - GROHE Atrio 47289000 Temperature Control Handle
