Inta ID02812ELVK Solenoid for HTM64 Infra Red Thermostatic Hospital Taps
SUMMARY
Inta ID02812ELVK is a solenoid for Inta sensor-operated infrared tap systems used on selected HTM64 wall mounted thermostatic hospital taps and IR120CP.1 / IR121CP1 basin mounted taps.
The solenoid opens and closes the water path when the infrared sensor and control system call for flow. Common faults linked to a worn or failed solenoid can include no water flow when the sensor is triggered, delayed shut-off, or intermittent touchless operation.
Technical Details
- - Part code: ID02812ELVK.
- - Power: 6V 450mA.
- - Outer fitting diameter: 20.7mm.
- - Distance between inlet and outlet: 61.4mm.
Before ordering check
- - Check the part code ID02812ELVK and your exact tap model before ordering.
- - Do not match this solenoid from appearance or dimensions alone.
Confirmed Used In Models
Inta HTMWMBCP HTM64 Safe Touch Infrared Thermostatic Wall Mounted Battery Operated Tap
Inta HTMWMMCP HTM64 Wall Mounted Infra-Red Thermostatic Hospital Tap Mains Operated
Inta HTMWMBRS HTM64 Wall Mounted Infra-Red Thermostatic Hospital Tap Battery Operated
Inta HTMWMMRS HTM64 Wall Mounted Infra-Red Thermostatic Hospital Tap Mains Operated
Inta IR120CP.1 Infrared Contemporary Battery Operated Basin Mounted Tap
Inta IR121CP1 Infrared Contemporary Basin Mounted Tap Mains Operated
Related Spares You May Need
- - Inta HTMSP4XX Hot Water Inlet Leg - hot side inlet leg for the wall mounted HTM64 tap body.
- - Inta HTMSP3XX Cold Water Inlet Leg - cold side inlet leg for the wall mounted HTM64 tap body.
- - INTA HTMSP5XX Filter and Check Valve Assembly - filter and check valve assembly used in the HTM64 wall mounted tap system.
- - Inta HTMSP2XX Thermostatic Cartridge for HTM64 Hospital Taps - thermostatic cartridge used in the HTM64 wall mounted tap platform.
- - INTA HTMFLUSH Flushing Kit for HTM Taps (Pairs) - flushing connector kit for servicing and system flushing.
- - Inta HTMSP6XX Lever Handle for HTMSP2XX Cartridge - lever handle for lever operated wall mounted HTM64 models.
- - Inta HTMSP17XX Infrared Touchless Tap Sensor - sensor assembly for infrared wall mounted HTM64 models.
- - INTA HTMSP10XX Battery Case for HTM Tap - battery casing for battery operated infrared wall mounted HTM64 models.
- - HTMSP13XX HTMSP13XX Cable for Solenoid to Sensor for HTM Taps - sensor cable used on infrared wall mounted HTM64 models.
- - Inta IR08002199 Self Adjusting Sensor for IR120/121 - sensor assembly listed on the IR120CP1 and IR121CP1 tap spare pages.
- - Inta IR06530020 Battery Box cw Batteries and Fixing Kit - battery pack and fixing kit used on the battery operated IR tap platform.
- - Inta IR07230002 Solenoid Unit cw Diaphragm - related solenoid unit shown on the IR120CP1 and IR121CP1 spare pages.
- - INTA IR303 Remote Control - remote control accessory shown on the IR120CP1 and IR121CP1 spare pages.
- - Inta IR08510010 Aerator / Flow Limiter for IR120CP - 0.35 GPM - outlet flow limiter listed on the IR120CP1 and IR121CP1 spare pages.
- - Inta IR07231001 Solenoid Housing cw Filter and 10mm Spigot Adaptor - related solenoid housing assembly shown on the IR120CP1 and IR121CP1 spare pages.
- - Inta IR02515SENE Infrared Sensor for IR120CP.1 and IR121CP.1 Taps - infrared sensor for the IR120CP.1 and IR121CP.1 tap platform.
- - INTA ID02500AL6FL Transformer - transformer used on the mains operated IR tap platform.
