Vado CEL-RETROFIT/E3 Retrofit Kit Including Cartridge, Handle and Thermostop Ring for Celsius CEL-137T Valves
SUMMARY
Vado CEL-RETROFIT/E3 Retrofit Kit Including Cartridge, Handle and Thermostop Ring for Celsius CEL-137T Valves
The temperature control handle has a diameter of 40mm.
The thermostatic cartridge has 20 splines / 7.6mm diameter head.
This Vado CEL-RETROFIT/E3 is a thermostatic cartridge retrofit kit for Celsius CEL-137T valves. The kit includes the thermostatic cartridge, temperature control handle and thermostop ring needed when replacing the temperature control assembly on the CEL-137T valve.
This retrofit kit is used to restore thermostatic temperature control where the valve no longer regulates water temperature correctly, runs too hot or too cold, or has become difficult to set accurately. Check the installed valve model and cartridge head before ordering, especially where an older cartridge version may already be fitted.
Technical Details
- - Part number: CEL-RETROFIT/E3
- - Kit contents: thermostatic cartridge, handle and thermostop ring
- - Temperature control handle diameter: 40mm
- - Thermostatic cartridge spline count: 20 splines
- - Cartridge head diameter: 7.6mm
Confirmed Compatible Models
- - VADO CEL-137T-C/P Celsius Thermostatic Bath Filler Wall Mounted Spare Parts
Installation Note
Isolate the hot and cold water supplies before removing the old thermostatic cartridge assembly. Refit the thermostop ring in the correct position and check the valve temperature setting after installation. Apply a suitable silicone grease to cartridge O-rings during fitting to help protect the seals and ease installation.
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
