Inta TR00003XX Thermostatic Cartridge for TR10032CP
Send a photo of your item and we'll help confirm it.
Summary
Inta TR00003XX Thermostatic Cartridge used in TR10032CP TRADE TEC Single Outlet Bar Shower. Flow counterpart is TR00004XX
Inta TR00003XX is a thermostatic cartridge used in the TR10032CP Trade-Tec single outlet bar shower. This temperature cartridge sits inside the shower valve body and controls the blended hot and cold water temperature delivered through the outlet.
The cartridge is separate from the flow-control cartridge and should be checked against the part removed from the shower before ordering. A faulty or scaled thermostatic cartridge can cause poor temperature control, unstable mixed water temperature or difficulty achieving the correct showering temperature.
Technical Details
| Brand | Inta / Intatec |
|---|---|
| Part Number | TR00003XX |
| Part type | thermostatic cartridge / temperature cartridge |
| Application | temperature-control cartridge for selected Inta single outlet thermostatic bar shower valves |
| Flow counterpart | Inta TR00004XX Flow Cartridge |
| TR10032CP factory temperature setting | 38 degrees C |
| TR10032CP minimum operating pressure | 0.2 bar dynamic |
| TR10032CP maximum inlet pressure | 12 bar static / 5 bar dynamic |
| TR10032CP inlet connection | G3/4 inch |
| TR10032CP outlet connection | G1/2 inch |
After fitting a new TR00003XX thermostatic cartridge, the shower valve should be re-calibrated so that the 38 degrees C stop aligns correctly with the valve body marking under the site supply conditions.
Confirmed Compatible Models
- Inta TR10032CP Trade-Tec Thermostatic Bar Shower with Flexible Riser Kit
- Inta IX100010CP Enzo Single Outlet Thermostatic Shower with Flexible Riser Kit and Handset
Before Ordering
- Check the removed cartridge code against TR00003XX before ordering
- Check that the fault is temperature related rather than flow related
- If the valve has low flow or poor shut-off, inspect the TR00004XX flow cartridge and inlet filters as well
- Isolate both hot and cold water supplies before removing the cartridge
Related Spares You May Need
- Inta TR00004XX Flow Cartridge - Part Number TR00004XX
- TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved - Part Number TAC86
