Crosswater X2A037N On/​Off Shower Diverter Cartridge for KL0007WC Valves

SUMMARY

Crosswater X2A037N On/Off Shower Diverter Cartridge for Kai Lever KL0007WC

The Crosswater X2A037N is an on/off shower diverter cartridge for the Crosswater Kai Lever KL0007WC wall-mounted diverter valve.

The cartridge controls water flow and selects between the valve's connected outlets. A worn or damaged cartridge can cause poor outlet selection or continued dripping from the shower head or spout when the valve is turned off. Check the valve and existing cartridge before ordering, as these symptoms can have more than one cause.

Technical Details

- - Part Number: X2A037N

- - Part type: on/off shower diverter cartridge

- - Total length: 83mm

- - Body diameter: 39mm

- - Brass spindle length: 39mm

- - Spindle width: 7.5mm

Confirmed Compatible Models

- - Crosswater Kai Lever KL0007WC Diverter Valve

Before Ordering

Confirm the KL0007WC valve code or X2A037N cartridge code, then compare the original cartridge's shape, spindle, locating features and dimensions. The 39mm body diameter alone is not sufficient to identify the correct cartridge.

Installation and Servicing

Isolate the water supply before dismantling the valve. Remove the handle, cover plate and threaded collar, then keep the washer and spindle safe before undoing the retaining nut. Note the cartridge's orientation before removal so that the new cartridge can be positioned correctly.

If cleaning the existing cartridge, rinse it with clean running water, dry it and lightly lubricate the seal. Apply suitable silicone grease sparingly to the cartridge seals during installation and servicing.

Related Spares You May Need

- - TACSIL 3g WRAS Approved Silicone Grease - TAC86 for lubricating cartridge seals during installation and servicing

- - NXT734 Shower Hose for separate hose replacement; check the required hose length and end connections before ordering

If you are unsure which cartridge you need, use our part identification service.
