Dornbracht 9015020650090 XTool Thermostatic Cartridge and Temperature Handle Assembly (Villeroy & Boch)
Send a photo of your item and we'll help confirm it.
Summary
Dornbracht 9015020650090 is a thermostatic cartridge with regulator unit for selected xTOOL concealed shower thermostat installations.
It controls the mixed water temperature inside the concealed valve and is used where temperature regulation has become inaccurate, stiff, unstable or inconsistent.
Official spare parts data for this service part identifies an approximately 44 mm x 147 mm thermostatic cartridge assembly with a rated flow of 50 l/min.
It is used in 3/4 inch xTOOL concealed thermostat configurations including no-volume-control trims and selected xTOOL module builds with additional valves.
Technical Details
| Part code | 9015020650090 |
|---|---|
| Part type | thermostatic cartridge with regulator unit |
| Application | xTOOL concealed shower thermostat |
| Size | approximately 44 mm x 147 mm |
| Rated flow | 50 l/min |
Before you order check
- Check the exact cartridge code on the removed part or against the spare parts breakdown for your valve
- Check that your valve is an xTOOL concealed thermostat build and not a different 1/2 inch or non xTOOL version
- Check whether your valve uses separate finish-specific handle parts and non return valve components from the related spare list below
Confirmed Compatible Models
- Dornbracht Symetrics xTOOL Concealed Thermostat without Volume Control 36417980
- Dornbracht xTOOL Concealed 3552697090
- Villeroy & Boch / Dornbracht xTOOL 3551697090
- Villeroy & Boch / Dornbracht xTOOL 3554697090
- Dornbracht Lulu xTool Concealed Thermostat without Volume Control 3/4 Inch Chrome 36 503 710-00
- Dornbracht Madison xTool Concealed Thermostat without Volume Control 3/4 Brushed Platinum 36 503 977-06
- Dornbracht Tara xTool Concealed Thermostat without Volume Control 3/4 Matte Black 36 503 892-33
- Dornbracht Series Specific xTool Concealed Thermostat without Volume Control 3/4 Platinum 36 503 979-08
Related Spares You May Need
- Dornbracht 04173300401-08 Platinum Finish Temperature Control Handle Knob
- Dornbracht 09230104590 Non Return Valve
- Dornbracht 04173300401-00 Temperature Control Handle Knob
- Dornbracht 9090031430090 Flow Cartridge Assembly - Anti-Clockwise Open
- Dornbracht 9090031420090 Flow Cartridge Assembly - Clockwise Open
- Dornbracht 04173300801-00 Temperature Control Handle
- Dornbracht 0421340770090 Non Return Valve Holder
- Dornbracht 9023010450090 Back-Flow Preventer - 20mm Non Return Valve
- Dornbracht 04173300401-06 Platinum Matte Control Handle
- Dornbracht 9016020270090 Spring for Button
- Dornbracht 1217897090 Extension 46mm
