Dornbracht 09230104590 Non Return Valve - D-09230104590
SUMMARY
Dornbracht 09230104590 is a non-return valve and back-flow preventer for selected Dornbracht concealed thermostat and xTOOL shower valve assemblies. The Di Vapor Part Number is D-09230104590.
This check valve helps control one-way water movement inside the valve body and is used where the spare parts breakdown identifies Dornbracht code 09230104590 or spaced code 09 23 01 045 90. A faulty or contaminated non-return valve can contribute to reverse flow cross-flow between supplies or poor back-flow prevention within the concealed valve assembly.
Technical Details
- - Brand: Dornbracht
- - Part code: 09230104590
- - Alternative spaced code: 09 23 01 045 90
- - Part type: non-return valve / check valve / back-flow preventer
- - Supplier designation found during research: DW 20
- - Function: helps prevent reverse water flow through the valve or thermostat assembly
- - Quantity note: selected xTOOL thermostat module breakdowns use two back-flow preventers
Confirmed Compatible Models
- - Dornbracht xTOOL concealed thermostat module without volume control 35 503 970 90
- - Dornbracht xTOOL concealed thermostat rough with one volume control 35 511 970-90 0010
- - Dornbracht xTOOL concealed thermostat rough with two volume controls 35 521 970-90 0010
- - Dornbracht xTOOL concealed thermostat rough 35 517 970-90 0010
Before You Order
- - Check the removed valve or Dornbracht spare parts diagram for 09230104590 or 09 23 01 045 90 before ordering
- - Do not select this part by size alone as Dornbracht uses similar non-return valve parts in nearby assemblies
- - Do not confuse this listing with Dornbracht 9023010450090 Back-Flow Preventer - 20mm Non Return Valve (NRV) which is listed separately by Di Vapor
- - If your valve identity is uncertain compare the removed part with the product images or contact Di Vapor before ordering
Related Spares You May Need
- - Dornbracht 9023010450090 Back-Flow Preventer - 20mm Non Return Valve (NRV)
- - Dornbracht 0421340770090 Non Return Valve Holder
- - Dornbracht 1217797090 28mm Extension Kit
- - Dornbracht 1217897090 Extension 46mm
- - Dornbracht 9090031430090 Flow Cartridge Assembly - Anti-Clockwise Open
- - Dornbracht 9090031420090 Flow Cartridge Assembly - Clockwise Open (90 90 03 142 00 90)
- - Dornbracht 04173300401-00 Temperature Control Handle Knob
- - Dornbracht 04173300401-06 Platinum Matte Control Handle (90173300400-06)
