Dornbracht 90173300400-00 Shower Valve Control Handle - Chrome (Villeroy & Boch 04173302000-00)
Send a photo of your item and we'll help confirm it.
Summary
Dornbracht 90173300400-00 is a chrome shower valve thermostat control handle for selected Dornbracht xTOOL concealed thermostatic shower valve applications. Di Vapor also lists this handle with Villeroy & Boch code 04173302000-00.
This part replaces the visible control handle used on the thermostat interface. It is the handle only and does not include the thermostatic cartridge, cartridge extension, spring or black handle button repair kit unless those parts are ordered separately.
Technical Details
| Part code | 90173300400-00 |
|---|---|
| Manufacturer formatted code | 90 17 33 004 00-00 |
| Part type | thermostat shower valve control handle |
| Finish | Chrome |
| Approximate size | 46mm diameter x 48mm length |
| Application | selected Dornbracht xTOOL concealed thermostatic shower valves without volume control |
When To Replace
Replace this handle if the existing control handle is cracked, missing, worn, loose on the control spindle or no longer gives reliable grip when adjusting the thermostat. If the water temperature is unstable, stiff to adjust or inaccurate, check the thermostatic cartridge and temperature handle carrier parts as well because the handle alone may not correct an internal valve fault.
Before You Order
- Match the full code 90173300400-00 or 90 17 33 004 00-00 against the removed handle or valve spare parts diagram
- Check the complete xTOOL valve article number before ordering
- Do not order by diameter or appearance alone because similar Dornbracht handles are used on other valve families
Confirmed Compatible Models
- Dornbracht Series Specific xTool Concealed Thermostat without Volume Control 1/2 Inch Chrome 36 501 780-00
- Dornbracht Series Specific xTool Concealed Thermostat without Volume Control 1/2 Inch Chrome 36 501 979-00
- Dornbracht Series Specific xTool Concealed Thermostat without Volume Control 3/4 Inch Chrome 36 503 780-00
- Dornbracht Series Specific xTool Concealed Thermostat without Volume Control 3/4 Inch Chrome 36 503 979-00
- Dornbracht xTool Concealed Thermostat without Volume Control 1/2 Inch 3650197900
Related Spares You May Need
- Dornbracht 9015020700090 Thermostat Cartridge (Villeroy & Boch)
- Villeroy & Boch 09.15.02.065.90 X TOOL 3/4 Thermostatic Cartridge
- Dornbracht 04173300801-00 Temperature Control Handle (04173300501-00 & 04173300401-00 Compatible Spare)
- Dornbracht 9015020630090 Thermostatic Cartridge
- Dornbracht 9015020650090 XTool Thermostatic Cartridge and Temperature Handle Assembly (Villeroy & Boch)
- Dornbracht 9016020270090 Spring for Button
- Dornbracht 1217897090 Extension 46mm
- Dornbracht 90213301100-13 Repair Kit for Black Handle Button (A924153, 09213305090, 09213305190)
If the handle or valve article number does not match, send a clear photo of the removed handle, valve faceplate and cartridge area before ordering.
