Hansgrohe 96364000 O-ring Set 32x2.5mm
Send a photo of your item and we'll help confirm it.
Summary
Hansgrohe 96364000 O-Ring Set 32 x 2.5mm for Basin and Bidet Mixers
Hansgrohe 96364000 O-ring set for the control-handle escutcheon assemblies of selected Hansgrohe and AXOR 3-hole basin and bidet mixers. This is a sealing component, not a complete cartridge or stop-valve assembly.
The O-ring fits beneath the individual control-handle escutcheon, above the stop-valve fixing components. It seals this part of the assembly and is separate from the ceramic shut-off cartridge that controls water flow.
Technical Details
| Manufacturer part code | 96364000 |
|---|---|
| Component type | O-ring seal |
| O-ring size | 32 x 2.5mm |
| Installation position | beneath the control-handle escutcheon |
Confirmed Compatible Models
- Hansgrohe Logis 71133000 3-hole basin mixer 150 with pop-up waste set - Chrome - 04/2014 to 12/2014
- Hansgrohe Logis 71133000 3-hole basin mixer 150 with pop-up waste set - Chrome - from 01/2015
- Hansgrohe Logis Classic 71323000 3-hole basin mixer 150 with pop-up waste set - Chrome - 01/2015 to 02/2018
- Hansgrohe AXOR Bouroullec 19121000 3-hole basin mixer 130 with pop-up waste set - Chrome - 10/2010 to 12/2017
- Hansgrohe AXOR Bouroullec 19122000 3-hole basin mixer 170 with pop-up waste set - Chrome
- Hansgrohe AXOR Bouroullec 19141000 3-hole basin mixer 155 without pull-rod - Chrome
- Hansgrohe AXOR Bouroullec 19213000 3-hole bidet mixer with pop-up waste set - Chrome - 10/2010 to 12/2014
Before Ordering and Fitting
Check the complete mixer article number, production period and original seal position before ordering. These mixers contain several different O-rings, so do not select a seal from diameter alone. Isolate the hot and cold water supplies before dismantling the mixer, clean the sealing surfaces and take care not to twist or damage the new O-ring during fitting.
Related Spares You May Need
The following items are available separately. The Logis and Bouroullec models use different shut-off cartridges, so check the exact application and operating direction before ordering.
- TACSIL 3g silicone grease - lubricant for O-rings and seals during assembly
- Hansgrohe 97357000 complete stop-valve assembly - the valve assembly beneath the individual water control
- Hansgrohe 98127000 pair of O-rings - separate spout seals for the listed Logis and Logis Classic mixers
- Hansgrohe 94184000 handle fixing adapter - for the listed Logis 71133000 mixers
- Hansgrohe 96765000 anti-clockwise-close flow cartridge - for the listed Logis and Logis Classic mixers
- Hansgrohe 96766000 clockwise-close flow cartridge - compatible replacement - for the listed Logis and Logis Classic mixers
- Hansgrohe 94149000 half-turn ceramic disc cartridge - anti-clockwise turn on - for the listed AXOR Bouroullec mixers
Use the Di Vapor part identification service if you need help finding the right part.
