Ultra VH008 Tec Pura Temperature Control Handle (Crosshead)

SUMMARY

Ultra VH008 Tec Pura Temperature Control Handle (Crosshead) for Thermostatic Shower Valves

Note: Used on 20 spline cartridges.

The Ultra VH008 is a temperature-control crosshead handle used on selected Tec and Tec Pura concealed thermostatic shower valves from Hudson Reed and Ultra. It provides the manual control for adjusting the thermostatic temperature setting and is used on 20-spline cartridge spindles.

This is a shower-valve handle rather than a lever cartridge. Before ordering, confirm the shower valve model and check the cartridge spindle, as a 20-spline count alone does not confirm fitment.

Technical Details

- - Part number: VH008

- - Part type: temperature-control crosshead handle

- - Function: thermostatic temperature adjustment

- - Spindle interface: 20 splines

Confirmed Compatible Models

- - A3003 Ultra Tec Pura Plus Triple Thermostatic Shower Valve

- - A3003V Hudson Reed Tec Pura Twin Concealed Thermostatic Shower Valve

- - A3007 Hudson Reed Tec Pura Concealed Twin Shower Valve with Built-in Diverter

- - A3023 Hudson Reed Tec Pura Plus Concealed Thermostatic Triple Shower Valve with Diverter

- - A3006 Hudson Reed Tec Twin Concealed Thermostatic Shower Valve with Diverter

- - A3098 Hudson Reed Tec Twin Concealed Thermostatic Shower Valve

The confirmed valve families were produced with different internal cartridge arrangements, so match the existing cartridge and valve version before ordering related cartridges or valve internals.

Related Spares You May Need

- - Hudson Reed A3003 Thermostatic Cartridge - Plastic A3003PL

- - Hudson Reed SA30049 Thermostatic Cartridge - ULTRA Original Version

- - SC50T20 Crosswater Thermostatic Cartridge - Valquest SC50-T20 and SC50T20-M

- - Ultra SACDV 3/4" Flow Cartridge Hudson Reed Headwork Ceramic Disc

- - SVR21 Ultra 3/4" Ceramic Disc Quarter Turn Cartridge

- - SVR22 87mm Ultra Hot Flow On/Off Cartridge

- - Ultra SVR21W G 3/4" Cold CD Valve Flow Cartridge

- - Ultra SVR22W G 3/4" Hot CD Valve WRAS Approved

- - Ultra SVQ07 Diverter Cartridge for A3023 Triple Shower Mixer Valves

- - Ultra SVQ01 3/4 Tapered Conical Nut & Washer

- - Ultra SVQ02 Non-Return Valve Housing

- - Ultra V068-P Ov20 20mm Check Valve - Non-Return Valve

- - Ultra SVQ05 Shroud For Valquest Twins / Triples

- - Ultra SVQ15 Non-Return Valve Concealed NRV

If you are unsure whether VH008 is the correct handle, use the Di Vapor Part Identification Service.
