Hudson Reed Tec Pura Plus Concealed Thermostatic Triple Shower Valve With Diverter Spare Parts
SUMMARY
Hudson Reed Tec Pura Plus Concealed Thermostatic Triple Shower Valve With Diverter SparesProduct Type: Showers / Shower Valves / Showers
All spares available for this product are below:
You will receive the original version of this cartridge as per the photos and not the cheap copy that is being sold in the market. This is a replacement screw in thermostatic cartridge for Hudson Reed SA30049 Ultra Group twin and triple valves which were mainly sold pre 2010. ...
This is a replacement flow cartridge for Hudson Reed SACDV, also known as Ultra SACDV. The sister part for this SACDV flow cartridge is the SA30049 thermostatic cartridge. Total Length: 54mm Number of Splines/Teeth: 20 Diameter of Splines/Teeth: 7.7mm Main Body Diameter: ...
SC50 T20 TMV2 Thermostatic Cartridge Replacement. The SC50-T20 (SC50T20) is used on the following shower mixer valve - Crosswater Totti Thermostatic Shower Valve - CROSSWATER-PARENT-3 - Hudson Reed Tec Pura Showers - Hudson Reed REI3407 Reign Twin Concealed Shower Va...
Ultra SVQ01 3/4 Tapered Conical Nut & Washer Top Internal Diameter: 18.3mm Bottom Screw Thread diameter: 24.5mm...
Ultra SVQ04 Flow Cartridge Shroud Diameter: 37.8mm Height: 39.5mm
Ultra SVQ05 Shroud For Valquest Twins / Triples
Ultra SVQ07 Diverter Cartridge for A3023 Triple Shower Mixer Valves Technical Information Total Length: 100mm (10cm) Diameter of Main Barrel: 40mm (4cm) Distance Between Locating Pins (centre to centre): 22mm (2.2cm) Length of Barrel Body (Including Locating Pins): 50mm S...
SVR21 Ultra 3/4" Ceramic Disc Quarter Turn Cartridge for ART3210 Shower Valves - Clockwise close (anti-clockwise open). Total Length (including bottom seal): 85.7mm Diameter at Widest Point: 28.5mm Top Spline Diameter: 7.8mm Top Spline Teeth / Notches: 20 Barrel Diameter: ...
Ultra VH008 Tec Pura Temperature Control Handle (Crosshead). Used on 20 spline cartridges....
Hudson Reed VH008A Tec Pura Flow Lever Handle (Ultra Finishing) Diameter at widest round part: 40mm Diameter of bottom round part: 32mm Diameter of Top round part which says HR: 28mm Length of Lever Rod: 47mm Number of Splines: 20...
Hudson Reed VPS002 Triple Rectangular Plate (Round Flanges)
Ultra SVR21W G 3/4" Cold CD Valve Flow Cartridge
