Dornbracht 9018400770190 Sleeve
Part number: 9018400770190
Price: £36.00
Sale: £26.66
You save: £9.34 (26%)
Price includes UK VAT (Region: UK▼)
In stock
Is this the right part?
Send a photo of your item and we'll help confirm it.
Product description
Summary
Dornbracht 9018400770190 Brass Sleeve for Shower Valves and Mixers - Replaces 09184007790
Dornbracht 9018400770190 is the replacement brass sleeve for the previous Dornbracht part 09184007790. It is used internally in selected Dornbracht concealed thermostatic controls, volume-control assemblies, mixers and diverters.
The replacement part is identified as 9018400770190, with the manufacturer alternative code format 90 18 40 077 01 90. Older Dornbracht spare-parts diagrams identify the previous sleeve as 09184007790, also shown in manufacturer documentation as 09 18 40 077 90.
The sleeve fits within the valve assembly around the relevant internal cartridge, spindle or bore. Check the spare-parts diagram for your exact Dornbracht model before ordering, as the number of sleeves used can vary between assemblies.
Technical Details
| Replacement part code | 9018400770190 |
|---|---|
| Manufacturer alternative code format | 90 18 40 077 01 90 |
| Previous part code | 09184007790 |
| Previous manufacturer code format | 09 18 40 077 90 |
| Part type | brass sleeve |
| Quantity supplied | one sleeve |
| Application | selected Dornbracht concealed thermostats, volume controls, mixers and diverters |
Before You Order
- Check the spare-parts diagram for your exact Dornbracht model and look for either 9018400770190 or the previous 09184007790 reference
- Older diagrams may show 09 18 40 077 90 while newer spare-parts information may show 90 18 40 077 01 90
- Check the quantity required because some Dornbracht assemblies use more than one sleeve
- Isolate the water supply before dismantling the valve
Confirmed Compatible Models
- Dornbracht Madison Concealed Thermostat with Three-Way Volume Control Chrome 36 428 977-000010
- Dornbracht Madison Concealed Thermostat with One Function Volume Control Brushed Platinum 36 425 977-06
- Dornbracht Madison Concealed Thermostat with One Function Volume Control Platinum 36 425 977-08
- Dornbracht Madison Concealed Thermostat with Two Function Volume Control Platinum 36 426 977-08
- Dornbracht Madison Concealed Thermostat with Two Function Volume Control Brushed Dark Platinum 36 426 977-99
- Dornbracht Madison Concealed Thermostat with Three Function Volume Control Brushed Platinum 36 427 977-06
- Dornbracht Madison Concealed Thermostat with Three Function Volume Control Platinum 36 427 977-08
- Dornbracht Series Specific Concealed Thermostat with One Function Volume Control Brushed Platinum 36 425 670-06
- Dornbracht Series Specific Concealed Thermostat with One Function Volume Control Platinum 36 425 670-08
- Dornbracht Series Specific Concealed Thermostat with One Function Volume Control Brushed Platinum 36 425 970-06
- Dornbracht Series Specific Concealed Thermostat with One Function Volume Control Brushed Dark Platinum 36 425 970-99
- Dornbracht Series Specific Concealed Thermostat with Two-Way Volume Control Chrome 36 426 670-000010
- Dornbracht Series Specific Concealed Thermostat with Two Function Volume Control Brushed Platinum 36 426 670-06
- Dornbracht Series Specific Concealed Thermostat with Two Function Volume Control Platinum 36 426 670-08
- Dornbracht Series Specific Concealed Thermostat with Two Function Volume Control Matte Black 36 426 670-33
- Dornbracht Series Specific Concealed Thermostat with Two Function Volume Control Brushed Platinum 36 426 970-06
- Dornbracht Series Specific Concealed Thermostat with Two Function Volume Control Platinum 36 426 970-08
- Dornbracht Series Specific Concealed Thermostat with Three Function Volume Control Brushed Platinum 36 427 670-06
- Dornbracht Series Specific Concealed Thermostat with Three Function Volume Control Matte White 36 427 970-10
- Dornbracht Series Specific Concealed Thermostat with Three Function Volume Control Matte Black 36 427 970-33
- Dornbracht Series Specific Concealed Thermostat with Three Function Volume Control Brushed Dark Platinum 36 427 970-99
- Dornbracht Tara Concealed Thermostat with One Function Volume Control Platinum 36 425 892-08
- Dornbracht Tara Concealed Thermostat with Two Function Volume Control Brushed Platinum 36 426 892-06
- Dornbracht Tara Concealed Thermostat with Two Function Volume Control Platinum 36 426 892-08
- Dornbracht Tara Concealed Thermostat with Two Function Volume Control Matte White 36 426 892-10
- Dornbracht Tara Concealed Thermostat with Two Function Volume Control Matte Black 36 426 892-33
- Dornbracht Tara Concealed Thermostat with Two Function Volume Control Brushed Dark Platinum 36 426 892-99
- Dornbracht Tara Concealed Thermostat with Three Function Volume Control Brushed Platinum 36 427 892-06
- Dornbracht Tara Concealed Thermostat with Three Function Volume Control Platinum 36 427 892-08
- Dornbracht Tara Concealed Thermostat with Three Function Volume Control Matte White 36 427 892-10
- Dornbracht Tara Concealed Thermostat with Three Function Volume Control Brushed Dark Platinum 36 427 892-99
- Dornbracht Lisse Concealed Thermostat with Two-Way Volume Control Chrome 36 426 845-000010
- Dornbracht Lisse Concealed Thermostat with Two Function Volume Control Brushed Platinum 36 426 845-06
- Dornbracht Lisse Concealed Thermostat with Three Function Volume Control Brushed Platinum 36 427 845-06
- Dornbracht Lulu Concealed Thermostat with Three Function Volume Control Brushed Platinum 36 427 710-06
- Dornbracht TARA .LOGIC Concealed Thermostat Trim with One-Way Volume Control 36425970
- Dornbracht Gentle 36425720-00
- Dornbracht Gentle 36426720-00
- Dornbracht Lisse 36425845-00
- Dornbracht Lisse 36426845-00
- Dornbracht Lisse 36427845-00
- Dornbracht Yarre 36425832-00
- Dornbracht Yarre 36426832-00
- Dornbracht Yarre 36427832-00
Related Spares You May Need
- TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- Dornbracht 9090031700090 Diverter Cartridge
- Dornbracht 092067006-00 Flow Control Handle
- Dornbracht 09121205290 Handle Base Extension
- Dornbracht 09230112490 Thermostatic Cartridge Adapter
- Dornbracht 9015020130090 Thermostatic Cartridge
- Dornbracht 9015020120090 Thermostatic Cartridge Villeroy & Boch 90 15 02 012 00 90
- Dornbracht 09121205490 Adapter
- Dornbracht 09281015290 Regulator Stop Ring
- Dornbracht 9090031660090 Cartridge - Compatible Spare
- Dornbracht 9090031630090 Diverter Cartridge - 90.90.03.163.90 Compatible Spare
- Dornbracht 9012120520090 Handle Mount for Thermostatic Cartridge 09.12.12.052.90 TYPE T
Not sure this is the right part? Use the Di Vapor Part Identification Service and we can help identify what you need.
