Vado VD67354 Thermostatic Cartridge Replacement (112mm Long)
Part number: VD67354
Price: £129.95
Sale: £118.22
You save: £11.73 (9%)
Price includes UK VAT (Region: UK▼)
In stock
Is this the right part?
Send a photo of your item and we'll help confirm it.
Product description
Summary
Vado VD67354 Thermostatic Cartridge Replacement used in Vado Celsius CEL-1720-12-C/P, CEL-148RO-C/P concealed twin outlet thermostatic shower valves.
This cartridge is often used with the MIX-1/TEMP-C-C/P handle.
Technical Details
| Total length of cartridge | 112.7mmm (from top of spindle to bottom of metal body, not including wax thermostat element) |
|---|---|
| Width at widest point | 41.8mm (at thread) |
| Width at top o ring | 40mm |
| Width at middle o ring | 38.8mm |
| Width at bottom o ring | 35mm |
| Number of o rings | 3 |
| Number of filters | 2 |
| Material | Brass |
| Colour | Brass and white |
| Installation type | Screw |
| Element | Uses Vernet France Wax Element 5204 |
| Width of Top Spline | 7.6mm |
| Number of Teeth on Top Spline | 20 |
Used in the following valves:
Vado Celsius - Concealed Thermostatic Shower Valve 3/4" with Rectangular Backplate
