Ultra SA30047 Over Ride Button & Thermostat Shroud
SUMMARY
Ultra SA30047 Override Button and Thermostat Shroud for Thermostatic Shower Valves
The Ultra SA30047 is a chrome override button and thermostat shroud housing used on selected Ultra and Hudson Reed thermostatic shower valves. It forms part of the external temperature-control assembly and is separate from the thermostatic cartridge inside the valve.
The override housing works with the temperature-control stop to help position and operate the shower valve temperature handle. On the documented pre-2009 Ultra Exact A3004 arrangement, the override button is positioned against the preset 38 degree C temperature stop. Check the valve model, age and shape of the existing control parts before ordering, as later valves using similar model codes can have different internal and external components.
Technical Details
- - Part Number: SA30047
- - Part type: Thermostatic shower valve override button and thermostat shroud housing
- - Finish: Chrome
- - Position: External thermostatic temperature-control assembly
- - Documented preset override temperature on the pre-2009 A3004 valve arrangement: 38 degree C
- - The thermostatic cartridge is a separate component
- - Manufacturer-discontinued part with no confirmed superseding replacement code
Confirmed Compatible Models
- - Ultra A3003 Tec Pura Plus Triple Thermostatic Shower Valve
- - Hudson Reed Tec Pura Twin Concealed Thermostatic Shower Valve A3003V
- - Ultra Exact Twin Control Shower Valve A3004 - pre-2009
- - Hudson Reed Tec Pura Concealed Twin Shower Valve With Built-in Diverter A3007
Before Ordering
For A3004 valves, SA30047 fitment is specifically confirmed for the pre-2009 Ultra Exact version. Later A3004 configurations should not be assumed to use this part. Compare the existing override button, shroud and valve model before ordering.
If you are unsure whether this is the correct part, use the Di Vapor Part Identification Service.
Related Spares You May Need
- - Hudson Reed SA30049 Thermostatic Cartridge - ULTRA Original Version
- - Ultra SACDV 3/4" Flow Cartridge Hudson Reed - Headwork - Ceramic Disc
- - Ultra SAG30249 Handle Assembly for SA30049 Thermostatic Cartridge
- - 56446SS Spline Adapter 7.6mm 24 Spline to 15.5mm 20 Spline
- - Hudson Reed Shower Valve Thermostatic Control Handle TV3566
- - Ultra SVQ02 Non-Return Valve Housing
- - Ultra V068-P Ov20 20mm Check Valve - Non-Return Valve
- - Hudson Reed SAG30212 Traditional Shower Handle for SA30049 and SACDV Cartridge
