Grohe 45882000 Ceramic Headpart Cartridge - 1/​2" - 1/​4 Turn - Anti-Clockwise Open

SUMMARY

GROHE 45882000 1/2 Inch Quarter-Turn Ceramic Tap and Shower Cartridge Anti-Clockwise Opening

The GROHE 45882000 is a nominal 1/2 inch ceramic headpart cartridge for the flow controls of specified GROHE taps and shower valves. It opens anti-clockwise and closes clockwise through a quarter turn.

The headpart controls water flow using ceramic sealing discs. It is used in the individual controls of selected two-handle kitchen and basin mixers, pillar taps, concealed basin mixer bodies and shower valves. It is a flow-control component, not a thermostatic temperature-control cartridge.

Technical Details

- - Part number: 45882000

- - Part type: ceramic headpart / flow-control cartridge

- - Nominal size: 1/2 inch

- - Operating movement: 90 degrees / quarter turn

- - Opening direction: anti-clockwise

- - Closing direction: clockwise

- - Stop arrangement: right-hand stop

- - Sealing mechanism: ceramic sealing discs

- - Headpart spanner size: 17 mm

- - Shortened headpart references used in servicing diagrams: 45 882 and 45882

Check the Operating Direction Before Ordering

Select this headpart by the exact fitting model, production version, handle arrangement and opening direction. It is not exclusively a hot-side or cold-side cartridge: its position depends on the fitting and the handles installed. Some cross-handle arrangements use 45882000 on both supplies. The nominal 1/2 inch designation is not an outside-diameter measurement and does not establish fit on its own.

Confirmed Applications

- - GROHE 30189000 GEN1 Ambi Two-Handle Sink Mixer, 2011 to 2016 version

- - GROHE 30189EN0 Ambi Two-Handle Sink Mixer, brushed nickel

- - GROHE 30190000 GEN1 Ambi Cosmopolitan Two-Handle Sink Mixer, 2011 to 2016 version

- - GROHE 30337000 Ambi Cosmopolitan Two-Handle Sink Mixer

- - GROHE 30489000 Ambi Cosmopolitan Two-Handle Sink Mixer

- - GROHE 20342000 Allure Brilliant Three-Hole Basin Mixer S-Size

- - GROHE 20344000 Allure Brilliant Three-Hole Basin Mixer M-Size

- - GROHE 20351000 Eurocube Three-Hole Basin Mixer S-Size

- - GROHE 29025002 Two-Handle Basin Mixer Concealed Body

- - GROHE 30192000 Atrio Two-Handle Sink Mixer, Jota handle arrangement

- - GROHE 30362000 Atrio Two-Handle Sink Mixer

- - GROHE 30362AL0 Atrio Two-Handle Sink Mixer

- - GROHE 30362DC0 Atrio Two-Handle Sink Mixer

- - GROHE 21019AL3 Atrio Cross-Handle Basin Mixer L-Size, using 45882000 on both hot and cold controls with the cross-handle arrangement

- - GROHE 18693000 Petita Basin Pillar Tap

- - GROHE 34725000 Grohtherm Special Thermostatic Bar Shower Mixer, flow-control headpart

- - GROHE JP259401 Grandera Two-Handle Basin Mixer

- - GROHE JP259400 Grandera Two-Handle Basin Mixer

Related Spares You May Need

Choose the associated components for your exact fitting. An opposite-rotation headpart, cartridge seat and handle connection set serve different purposes and are not required for every installation.

- - GROHE 45883000 Clockwise-Opening Ceramic Headpart, the opposite-rotation quarter-turn headpart used alongside 45882000 in specified two-handle arrangements, not a same-direction substitute

- - GROHE 0392400M Pack of 10 O-Rings, associated headpart seals with a specified size of 18.2 x 1.7 mm

- - GROHE 45023000 Flow Cartridge Seat, a model-specific associated seat for the 29025002 concealed basin mixer body, not a required component for every application of 45882000

- - GROHE 45186000 Handle Fixing Connection Set, an associated handle connection component in the Grandera JP259401 and JP259400 arrangements, subject to the installed handle assembly

- - TACSIL 3g Cartridge Silicone Grease, an optional servicing consumable for suitable cartridge seals and O-rings

Failure Symptoms and Servicing

Symptom: water continues dripping from the tap spout or shower head after the control has been turned off. Likely cause: the flow-control headpart or its associated seals may no longer be shutting off correctly. Solution: identify the affected control, check the headpart and sealing surfaces, and replace the faulty component after confirming the exact part required.

Before servicing, isolate the relevant hot and cold water supplies and follow the instructions for the complete fitting. Check the condition of the associated seals and seat, refit the handle in the correct operating position, and check for leaks after restoring the water supply. Do not force the control beyond its quarter-turn stops.

For help identifying an uncertain fitting, contact our part identification service with photographs of the complete tap or shower valve, the removed cartridge and any model or part markings.
