Grohe 23039002 Eurostyle Cosmopolitan Pillar Tap XS-Size Spare Parts

SUMMARY

Spares for GROHE 23039002 Eurostyle Cosmopolitan Pillar Tap XS-Size

The GROHE 23039002 Eurostyle Cosmopolitan is a chrome, XS-size basin pillar tap designed for single-hole installation. This single-inlet tap can be connected directly to a cold-water supply or to the outlet of a pre-mixed water supply.

The metal lever operates a 1/2-inch ceramic headpart, which controls and shuts off the water flow. The internal components can be serviced individually if the tap becomes difficult to operate or continues dripping from the outlet after it has been turned off.

Technical Details

- - Brand: GROHE

- - Range: Eurostyle Cosmopolitan.

- - Category: Basin tap.

- - Product code: 23039002.

- - Size: XS-size.

- - Finish: GROHE Long-Life chrome.

- - Installation type: Single-hole, deck-mounted installation.

- - Water inlet: Single inlet for cold or pre-mixed water.

- - Supply connection: G 1/2.

- - Ceramic headpart size: 1/2 inch.

- - Ceramic headpart operating rotation: 90 degrees.

- - Overall tap height: 129 mm.

- - Spout reach: 93 mm.

- - Outlet height: 66 mm.

- - Outlet angle: 17 degrees.

- - Base diameter: 50 mm.

- - Mounting opening diameter: 34 mm.

- - Maximum mounting surface thickness: 20 mm.

- - Minimum dynamic pressure: 0.5 bar.

- - Recommended operating pressure: 1 to 5 bar.

- - Maximum operating pressure: 10 bar.

- - Approximate flow rate: 8 litres per minute at 3 bar.

Common Faults and Checks

Water continuing to drip from the tap outlet after the lever has been closed can indicate wear or damage within the ceramic headpart. Stiff or loose lever movement can also be caused by worn headpart seals or handle connection components.

Before you order, check the tap code and compare the required component with the part being removed. Isolate the water supply before servicing the tap, flush the pipework, and inspect the sealing surfaces for scale or damage before fitting the replacement components.
