Crosswater CGPRO2000C 3/​4" Ceramic Disc Flow Cartridge (On/​Off) - Clockwise Open, 90mm, 20 splines

SUMMARY

Crosswater CGPRO2000C 3/4" Ceramic Disc Flow Cartridge (On/Off) - Clockwise Open, 90mm, 20 Splines

Crosswater CGPRO2000C is a ceramic disc on/off flow cartridge used in selected Crosswater concealed thermostatic shower valves. This screw-in cartridge opens clockwise and closes anti-clockwise.

Fitted beneath the flow control handle, it controls water flow and shut-off. The valve's separate thermostatic cartridge regulates the water temperature.

Dripping from the shower head or spout when the valve is turned off can indicate a problem with the flow cartridge. Limescale or debris can prevent full closure, so follow the valve's maintenance instructions when inspecting or cleaning the existing part.

Technical Details

- - Part Number: CGPRO2000C

- - Part type: ceramic disc on/off flow cartridge

- - Application: concealed thermostatic shower valves

- - Nominal size: 3/4 inch

- - Fitting: screw-in

- - Overall length: 90mm

- - Spindle length: 50mm

- - Spindle spline count: 20

- - Opening direction: clockwise

- - Closing direction: anti-clockwise

Before Ordering

Check the exact valve model and generation, opening direction, overall length, spindle length, spline count and sealing arrangement against the existing cartridge. Model names and dimensions alone are not sufficient to identify the correct part.

CGPRO1000H and X2A071N open anti-clockwise. Match the opening direction to the exact valve version and control position.

Confirmed Compatible Models

Mike Pro / MPRO

- - PRO2000RC Thermostatic Shower Valve with Two Outlets

- - PRO2000RV Thermostatic Shower Valve with Two Outlets

- - PRO2001RC Thermostatic Shower Valve with Two Outlets

- - PRO2001RV Thermostatic Shower Valve with Two Outlets

- - PRO3000RC Thermostatic Shower Valve with Three Outlets

- - PRO3000RV Thermostatic Shower Valve with Three Outlets

- - PRO3001RC Thermostatic Shower Valve GEN1

- - PRO3001RV Thermostatic Shower Valve with Three Outlets

PRO3001RC fitment also includes the WLBP3001RC_V2 valve body. Confirm the full valve body reference before ordering.

Water Square

- - WS2000RC Thermostatic Shower Valve GEN1

- - WS2000RC-VS Slim Backplate Thermostatic Shower Valve GEN1

- - WS2001RC Thermostatic Shower Valve GEN1

- - WS2001RC-VS Slim Backplate Thermostatic Shower Valve GEN1

- - WS3000RC Thermostatic Shower Valve with 3 Way Diverter GEN1

- - WS3000RC-VS Slim Backplate Thermostatic Shower Valve with 3 Way Diverter GEN1

- - WS3001RC Thermostatic Shower Valve with 3 Way Diverter GEN1

- - WS3001RC-VS Slim Backplate Thermostatic Shower Valve with 3 Way Diverter GEN1

Central

- - CE2000RC+ Thermostatic Shower Valve GEN1

- - CE2001RC+ Thermostatic Shower Valve GEN1

- - CE3000RC+ Thermostatic Shower Valve with 3 Way Diverter GEN1

Kai Lever

- - KL2000RC Thermostatic Shower Valve GEN1

- - KL2001RC Thermostatic Shower Valve GEN1

- - KL3000RC Thermostatic Shower Valve with 3 Way Diverter GEN1

- - KL3001RC Thermostatic Shower Valve with 3 Way Diverter GEN1

Belgravia

- - BL2001RC+ Thermostatic Shower Valve GEN1

- - HG2001RC+ Thermostatic Shower Valve with Two Outlets

- - BL3001RC+ Thermostatic Shower Valve with 3 Way Diverter

- - HG3001RC+ Thermostatic Shower Valve with 3 Way Diverter

Waldorf

- - WF2001RC_CLV+ Chrome Lever Thermostatic Shower Valve with Two Outlets

- - WF3001RC_CLV+ Chrome Lever Thermostatic Shower Valve with 3 Way Diverter

- - WF3001RC_LV+ White Lever Thermostatic Shower Valve with 3 Way Diverter

- - WF3001RC_BLV+ Black Lever Thermostatic Shower Valve with 3 Way Diverter

Related Spares You May Need

Choose related parts by the exact valve model, generation and control position, matching each part code to the existing component. The WS3000RC-VS GEN1 items below apply only to versions fitted with the corresponding component.

- - Crosswater X2A044N-1 Diverter Cartridge - brass locking ring excluded

- - TACSIL 3g WRAS Approved Silicone Grease - TAC86

- - Crosswater CGPRO1500D Diverter Flow Cartridge - for the applicable multi-outlet valve version

- - Crosswater CGPRO1000H On/Off Flow Cartridge - anti-clockwise opening

- - Crosswater CA43-29 Thermostatic Cartridge - match the existing thermostatic cartridge code and valve version

- - Crosswater CGPRO1000T Thermostatic Cartridge - temperature control cartridge for the applicable valve version

- - Crosswater Z00717N Non-Return Valve Filter - for WS3000RC-VS GEN1 versions fitted with this filter

- - Crosswater Z0A363N Non-Return Valve - for applicable WS3000RC-VS GEN1 and WLBP3001RC_V2 / WLBP3001R_V2 assemblies

- - Crosswater X2A071N On/Off Flow Cartridge - anti-clockwise opening; select for the correct valve version and control position

- - SC50T20-M Thermostatic Cartridge - for WS3000RC-VS GEN1 versions using this cartridge

- - Crosswater H1T082C Handle Base - check the handle base fitted to the WS3000RC-VS GEN1 valve

- - Crosswater RN1000FA1 Retaining Nut - for the thermostatic assembly in WLBP3001RC_V2

- - Crosswater SSP004 Shower Valve Control Screws - for WLBP3001RC_V2 and WLBP3001R_V2 assemblies

- - Crosswater NRV1000FA1 Non-Return Valve - for WLBP3001RC_V2 and WLBP3001R_V2 assemblies

- - Crosswater X2A044N-1-COL Retaining Nut Collar - separate collar for the X2A044N-1 diverter cartridge

Fitting and Care

Isolate the hot and cold water supplies before removing the control handle or cartridge. Follow the maintenance instructions for the exact valve model, inspect the seating and seals, and clear debris from the housing before fitting the correctly identified cartridge.

Use our part identification service if you are unsure which cartridge you need.
