Bristan 00622206 Diverter Cartridge for Prism, Artisan, Chill, JS2, Oval, Qube and Quadrant Shower Valves
Part number: BRISTAN-00622206
Price: £13.78
Sale: £11.48
You save: £2.30 (17%)
Price includes UK VAT (Region: UK▼)
In stock
Is this the right part?
Send a photo of your item and we'll help confirm it.
Product description
Summary
Bristan 00622206 is a shower valve diverter cartridge used in Bristan concealed shower valves in the Prism, Artisan, Chill, JS2, Oval, Qube and Quadrant ranges. It is the internal selector cartridge that diverts water between outlets in dual outlet and diverter stopcock valve assemblies.
This part is typically replaced when the valve becomes stiff to turn, does not switch cleanly between outlets, or allows water to pass to the wrong outlet. Before ordering, match the exact Bristan valve code and cartridge details rather than ordering from diameter alone.
Technical Details
| Height | 81mm excluding locating pins. |
|---|---|
| Cartridge body diameter | 39mm and 40mm at the O-ring. |
| Brass spindle length | 39mm. |
| Distance between locating pins centre to centre | 22mm. |
| Spline diameter | 7.6mm with 20 splines / teeth. |
| Application | Bristan concealed shower valve diverter cartridge. |
| Pre-order check | confirm the valve code together with the spline count, locating pin spacing and main body dimensions. |
Confirmed Compatible Models
- Bristan PM TSHCDIV C Prism Concealed Dual Control Shower Valve with Diverter Spare Parts.
- Bristan PM SHC3DIV C Prism Concealed 3 Control Shower Valve with Diverter Spare Parts.
- Bristan AR2 TSHCDIV C Artisan Thermostatic Dual Control Recessed Shower Valve with Diverter Spare Parts.
- Bristan AR TSHCDIV C Artisan Thermostatic Recessed Shower with Adjustable Riser Spare Parts.
- Bristan CL SHCDIV Chill Concealed Dual Control Shower Valve with Diverter Spare Parts.
- Bristan CL SHC3DIV C Chill Concealed Thermostatic Shower with Diverter Stopcock Spare Parts.
- Bristan CL SHC3DIV CB Chill Three Control Thermostatic Concealed Valve Shower Valve Spare Parts.
- Bristan JS2 SHC3DIV C JS2 Thermostatic Recessed Shower Valve.
- Bristan OL SHCDIV C Oval Dual Control Concealed Shower Valve with Integral Diverter Spare Parts.
- Bristan QU SHCDIV C Qube Dual Control Shower Valve with Integral Diverter Spare Parts.
- Bristan QT TSHCDIV C Quadrant Thermostatic Concealed Shower with Integral Diverter Spare Parts.
Related Spares You May Need
- Bristan 00622415 Thermostatic Cartridge (Screw-in).
- Bristan 00515776 Cartridge Retaining Nut for QT 3WDIV C.
- Bristan OR 08015 O Ring (17.17mm x 1.78mm) (MZ).
- Bristan Nut 04335CSET-BL Compression Nut & Olive.
- Bristan WSHR 08210 Washer - Fibre 1/2.
- Bristan FX 06541 Fixing Kit (Screws + plugs).
- Bristan 00515534 Shroud for Prism Valves (Chrome).
- Bristan CAP 05262C Cap Chrome (MZ).
- Bristan Quadrant HD 05478CSET-BL Flow Control Knob / Handle.
- Bristan SHD 05470C Quadrant Temperature Handle Base.
- TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved.
