Hansgrohe 94283000 Thermostatic Cartridge for Ecostat 5001 Shower Valves

SUMMARY

Hansgrohe 94283000 Thermostatic Cartridge for Ecostat 5001 Shower Valves. Also known as Hansgrohe 94283 or 94 283.

The Hansgrohe 94283000 is a thermostatic cartridge for selected Hansgrohe Ecostat 5001 exposed thermostatic shower and bath/shower mixer valves. It is the temperature control cartridge used in the early Ecostat 5001 valve assemblies where the spare parts diagram specifies Hansgrohe 94283000.

This cartridge is also known as Hansgrohe 94283 and 94 283. It controls the mixed water temperature inside the thermostatic valve body and should be checked when the shower temperature becomes unstable, difficult to regulate, too hot, too cold, or no longer responds correctly to the temperature handle.

Technical Details

- - Brand: Hansgrohe

- - Product code: 94283000

- - Di Vapor Part Number: HANS-94283000

- - Part type: thermostatic cartridge / temperature control cartridge

- - Application: selected Hansgrohe Ecostat 5001 exposed thermostatic shower mixer and bath/shower mixer valves

- - Known code variants: Hansgrohe 94283 and 94 283

- - Diagram position: thermostat cartridge position on the relevant Ecostat 5001 spare parts diagrams

Confirmed Compatible Models

- - Hansgrohe 15360000 Ecostat 5001 Exposed Thermostatic Shower Mixer G 1/2 06/97 - 05/01

- - Hansgrohe 36340000 Ecostat 5001 Exposed Thermostatic Bath/Shower Mixer 05/97 - 05/01

- - Hansgrohe 36360000 Ecostat 5001 Exposed Thermostatic Shower Mixer G 1/2 06/97 - 05/01

- - Hansgrohe 36360520 Ecostat 5001 Exposed Thermostatic Shower Mixer G 1/2 11/97 - 05/01

Before You Order

Check the valve model code and production date range before ordering. Later Ecostat 5001 versions use a different thermostatic cartridge, so do not select this part for a later valve unless the spare parts diagram or existing cartridge code confirms 94283000.

Installation Note

Isolate the hot and cold water supplies before removing the old cartridge. Lightly lubricate the cartridge O-rings with a suitable silicone grease during fitting and make sure the cartridge is seated correctly in the valve body before refitting the handle and temperature stop components.

Troubleshooting

- - Symptom: water temperature fluctuates during use

- - Likely Cause: worn or scaled thermostatic cartridge or inlet check components

- - Solution: check the cartridge, filters and non-return valves against the valve diagram before replacing parts

- - Symptom: temperature handle turns but the outlet temperature does not change correctly

- - Likely Cause: failed thermostat control section or incorrect temperature stop setup

- - Solution: inspect the cartridge and recalibrate the temperature handle after fitting

Related Spares You May Need

- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved

- - Hansgrohe 94184000 Handle Fixing Adapter

- - Hansgrohe 94149000 1/2" On/Off Half Turn Ceramic Disc Cartridge Anti-Clockwise Turn On

- - Hansgrohe 94074000 Non Return Valves DW15 / DN10

- - Hansgrohe 95033000 16mm Non Return Valve

Use the valve model code and production date to confirm the correct Ecostat 5001 spare before ordering. If the code on the existing cartridge or valve diagram is unclear, use the Di Vapor part identification service before purchase.
