Summary

Vado HUB-002B-3/4 3/4 Inch Ceramic Cold Flow Cartridge (On / Off) - Quarter Turn Clockwise Close

Vado HUB-002B-3/4 Flow Cartridge Information

Measurements:

All WG-15951 Series of Valves

All WSB-148 Series of Valves

• CEL-128B/SQ-3/4 and CEL-149-3/4-C/P Vado Celsius
• ELE-248B-3/4 Vado Elements
• LIF148-B-3/4 Vado Life
• MIX148B-3/4 and MIX 128B-3/4 Vado Mix
• NOT-148B-3/4 Vado Notion
• NUA-148B-3/4 Vado Nuance
• ORI-148B-3/4 Vado Origins
• SOH-148B-3/4 Vado Soho
• WG-11901 Vado Prima Thermostatic Shower
• WG-15051 Vado Thermostatic Shower
• WSB-149-3/4-C/P and WSB-148-3/4-C/P Vado Westbury
• WG-15951 Vado Concealed Thermostatic Shower
• TIM-148-3/4 Vado Time
• TON-348B-3/4 Vado Tonic

Vado Shower Valve Repair: Hub-002B-3/4 Flow Cartridge

A thermostatic mixer shower will let out approximately 2.5 gallons of water per minute at 80 PSI. It mixes hot and cold water together to bring about the preferred temperature desired by the showerer. Weak water flow and leaks are hints that the shower cartridge is beginning to encounter problems. Below are flow cartridge HUB-002B-3/4 installation instructions for the 3-way Vado shower valves Celsius, Elements, Tonic, Mix, and Notion. All five shower valves are similar to each other except for the handle design.

1. Remove the flow and temperature control handles by undoing the grub screw. The grub screw can be found on the sides of the handle cap.

• The lever on the Celsius temperature control knob must be unscrewed to remove.

2. Remove all the rings – stop ring, cover rings, retaining rings, flow valve rings, and temperature valve ring. Then slip the cover plate out.

3. Undo the screw-in fitment flow cartridge.

4. Apply plumbing grease on the single outer O-ring of the Vado Hub-002B-3/4 cartridge. Insert and secure it in the valve housing.

5. Restore the cover plate and the rings.

6. Restore the valve handles.

• The lever flow control handles of the Celsius must be pointing downwards before attaching the grub screw.
• The override button on the temperature control handle of the Celsius, Elements, Tonic, and Mix must point upwards (at 12:00). Press the button and push the handle against the cartridge splines. Make sure the splines do not turn. Proceed to return the grub screw to fasten the handle.

Identifying the Right Cartridge You Need

Determining the correct replacement is very important before making a purchase.

You can locate the brand and ID number of your shower. Some cartridges have numbers on the barrel which is also useful. You can measure the cartridge to check which cartridge spare part is a match. You can also contact us and we will be happy to help you identify the right cartridge for your shower valve.
