Ideal Standard A952500NU11 Basin Tap 1/2 Dx 1/4 Turn Flow Cartridge Clockwise Close
Send a photo of your item and we'll help confirm it.
Summary
You will receive the latest brass version of this cartridge. A952500NU11 Ideal Standard 1/2 Dx 1/4 Turn Ceramic Disc Cartridge (Clockwise Close).
IMPORTANT - Please Read - This cartridge is used in basin taps and is NOT used in Trevi shower valves.
IMPORTANT - Please ReadIf you require the cartridge which is used in the Trevi Therm shower valves, the link to the cartridge you need is here: Trevi A952501NU11 Cold Side Flow Cartridge.
Technical Information
Total Height: 45.5mm (From top of screw at the top to the bottom of the cartridge)
Total Height: 43mm (From top (Excluding screw) at the top to the bottom of the cartridge)
Diameter at Bottom O-ring 23.9mm
| Diameter of Thread | 24.8mm |
|---|---|
| Diameter of Toothed spline | 9.3mm |
| Number of Teeth | 40 to 44 (Depending on the cut of vertical cuts) |
| Cold or Hot | This cartridge is for the hot side. |
| Close | Twist clockwise to close |
| Colours | Ideal Standard / Trevi manufacture the plastic body in both black and white. The colour of the body has no meaning. The metal part of the cartridge is brass and the top may have red on it. |
| Materials | Brass and plastic |
| Number of O-Rings | 2 |
This A952501NU11 cartridge is used in the following models:
- A7640AA Domi Duo dual control one taphole bath filler - no handles
- E7611AA Icarus dual control one taphole basin filler with pop-up waste - no handles
Frequently Asked Questions
Question: I need a cold counterpart that looks like this cartridge. What is the code for the cold?
Answer: The cold version of this cartridge is Trevi A952501NU11.
