Mira 1836.170 Flow Diverter Cartridge for Atom Coda ERD H05b MK3 Valves
Send a photo of your item and we'll help confirm it.
Summary
Mira 1836.170 Flow Cartridge for Atom Coda ERD H05b MK3 Valves
Technical Information
Total Height: 58.6mm (from top of spline at the top to the bottom of the cartridge, excluding locating pins)
Diameter at Main Body 35mm
| Diameter of Toothed spline | 7.6mm |
|---|---|
| Number of Splines/Teeth | 20 |
| Colours | Blue, Red, White |
| Materials | Brass and plastic |
Mira 1836.170 Resolves Shower Problems
Should the Mira Atom or Coda shower drip from one shower head while the other is in use, 1836.170 flow and diverter cartridge is what it takes to get the shower back to normal.
About the Mira Spare Part: 1836.170 is a push-fit flow diverter cartridge. It is a 35mm replacement cartridge with a 20 teeth spindle. At 3 Bar, the cartridge can handle at least 21 litres per minute (5.5 gallons per minute) water flow rate.
Common Problems: The most common causes of problems regarding the flow diverter are hard water sediments and/or wear and tear. Limescale can collect on the brass spindle which results in a stiff to turn handle. Wear and tear can affect the entire Mira 1836.170 from the spline to the bottom seal giving rise to leaks.
Fitting: Changing the Mira 1836.170 can be simple. Turn off the hot and cold water supply to the shower. Then remove the handle, the retaining nut, and take out and replace the diverter cartridge.
Contact Us: Do you have questions about the 1836.170 Mira replacement flow diverter cartridge? Here’s how you can reach us:
+ Find a Shower Part Service Page
+ WhatsApp 07754 173340.
Di Vapor is your friendly UK spares experts!
We are looking forward to serving your spares needs.
Mira 1836.170: Questions and Answers
Question: How do I remove the handle and replace the Mira 1836.170?
Answer: Handle removal process to access the Mira flow diverter cartridge part number 1836.170:
Mira Coda Pro ERD Bar Valve:
- Remove the screw cover. This is the small circular cap on the side of the flow control handle.
- With the cap removed, undo or loosen the retaining screw to remove the handle.
(1744.108 is the replacement thermostatic cartridge.)
Mira Atom ERD Bar Valve:
- Remove the round cap at the side of the flow control handle.
- Remove the screw and the subsequent parts to access the Mira 1836.170.
(1663.114 is the replacement thermostatic cartridge.)
*Before endeavoring the cartridge replacement, switch off hot and cold water supply to prevent scalding in case of accidental water flow.
