Thermostatic Cartridge for Mira Reflex 1744.108 EV and BIV Shower Mixer Bars Valves
Send a photo of your item and we'll help confirm it.
Summary
Thermostatic cartridge for Mira Reflex 1744.108 Shower Mixer Valve Bars.
This cartridge will fit the following models (yet not restricted to these):
- Mira Reflex - from 10/12 until present
- Mira Reflex EV
- Mira Reflex BIV
- Mira Reflex L87A
Mira 1744.108 Cartridge Technical Information
| Cartridge Length | 103.65mm |
|---|---|
| Diameter | 34.5mm (at the widest point) |
| Diameter at Top O'Ring | 32.2mm |
| Diameter at Bottom O'Ring | 30mm |
Diameter of top Spindle (which the temperature handle connects onto): 9.5mm
| Number of Teeth on Handle Splindle | 24 |
|---|---|
| Type | Push fit |
| Cartridge Material | Plastic nylon with brass spindle and Vernet France 0165 copper thermostat element |
| Number of O-rings | 3 |
| Tiers of Splines | 1 |
| Number of Gauze Filters | 2 |
The thermo cartridge will have to be replaced periodically depending upon how hard the water is in your area. If you have soft water then this cartridge will last many years, however in very hard water areas, lime scale build up will damage the inner workings of the cartridge which will effect the performance of your Reflex shower.
Therefore, if you're experiencing problems with regulating the water flow or temperature, the chances are that the cartridge in the bar valve is faulty. You will need to replace the cartridge at this point.
If you need help, send us a photo of what you need here.
