Hansgrohe 92371000 3-Way Diverter Cartridge
Send a photo of your item and we'll help confirm it.
Summary
Hansgrohe 92371000 Diverter Cartridge
The measurements of this Hansgrohe spare are:
| Diameter | 40.5mm |
|---|---|
| Diameter at O-ring | 44.7mm |
| Total Height | 107.4mm |
| Brass Spindle Length | 62mm |
| Splines | 20 |
Hansgrohe 92371000 is a ceramic diverter cartridge used inside selected two-hole rim-mounted bath mixer basic sets and finished bath mixer assemblies. The diverter changes the water path between the available bath mixer outlets using a brass 20-spline control spindle.
A worn or damaged diverter can cause difficulty selecting an outlet, water continuing from the unselected outlet or water dripping from the shower handset or bath spout when the mixer is turned off. Check the other valve cartridges and seals before ordering because similar symptoms can have more than one cause.
Technical Details
| Manufacturer code | 92371000 |
|---|---|
| Part type | ceramic diverter unit and cartridge |
| Removal and installation tool size | SW 27mm |
| Refitting torque | 15Nm |
Confirmed Compatible Models
- Hansgrohe Basic set for 2-hole rim-mounted thermostatic bath mixer 13550180 production 11/2001 to 07/2007
- Hansgrohe Basic Set for 2-Hole Rim Mounted Thermostat 13550180 production from 08/2007
- Hansgrohe Basic Set for 2-Hole Rim Mounted Bath Mixer 13159180 production from 04/2017
- Hansgrohe Basic Set for 2-Hole Rim Mounted Thermostat 13550187 production from 11/2018
- AXOR Basic set for 2-hole rim-mounted thermostatic bath mixer 15486180 production from 10/2017
- AXOR Uno 2-Hole Rim Mounted Thermostatic Bath Mixer 38480000 production 03/2002 to 09/2012
- Hansgrohe Metropol 2-Hole Rim Mounted Single Lever Bath Mixer with Loop Handle 74548000 production from 04/2017
- Hansgrohe Metropol 2-hole rim-mounted single lever bath mixer with lever handle 32548000 production from 04/2017
- Hansgrohe Ecostat 2-hole rim-mounted thermostatic bath mixer 15450090 production 10/2001 to 10/2011
- Hansgrohe Ecostat 2-hole rim-mounted thermostatic bath mixer 15450880 production 10/2001 to 12/2011
- Hansgrohe Ecostat 2-hole rim-mounted thermostatic bath mixer 15450810 production 10/2001 to 11/2009
- Hansgrohe Ecostat 2-hole rim-mounted thermostatic bath mixer 15450000 production 10/2001 to 12/2014
- Hansgrohe PuraVida 2-hole rim-mounted thermostatic bath mixer 15474400 production 12/2012 to 12/2017
Before Ordering
Check the exact bath mixer or concealed basic-set code and its production period before ordering. Do not identify this diverter from the body diameter or 20-spline spindle alone because other Hansgrohe cartridges can have similar measurements.
Related Spares You May Need
Related components vary by basic set and finished bath mixer and are not fitted in every installation.
- TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- Hansgrohe 97108000 Spline Adapter for Handle
- Hansgrohe 92160000 M4x35 Hexagon Socket Screw
- Hansgrohe 94282000 Thermostatic Cartridge for Axor Pharo and Other Valves
- Hansgrohe 94184000 Handle Fixing Adapter
- Hansgrohe 94074000 Non Return Valves DW15 / DN10
- Hansgrohe 95037000 Thermostatic Cartridge Seal Kit
- Hansgrohe 38993000 Handle - 10836318
- Hansgrohe 97212000 AXOR Carlton Red Push Button
- Hansgrohe 96338000 Rubber Screw Cover Cap - Grey
- Hansgrohe 92730000 Lever Cartridge M3 / M2
