Genuine Ideal Standard SV93467 Part
SV93467 Instructions - Cistern Outlet Valve Maintenance Procedure
- 180mm Height - 180mm Overflow
The cistern outlet valve should be checked and the seal cleaned periodically.
1. Turn off the water supply to the cistern and flush
2. Close toilet seat lid.
3. Remove cistern lid.
4. Remove valve body by gripping and turning anti-clockwise to unlock. Apply downward pressure whilst turning the valve, (to prevent clips breaking). Lifting the valve body exposes the valve seal.
5. Inspect and clean valve seal
6. If necessary replace valve seal by removing the retaining clip and inserting screwdriver down centre hole as shown.
7. Check condition seal face, remove any obstruction.
8. Refitting the valve is reversal of removal, taking care to locate the tabs of the valve body into the lugs of the valve seat.
9. Re-fit cistern lid and turn on the water. Re-fill cistern test flush and sealing.
Free flow Outlet Valve
Overflow should be between 25mm and 42mm above waterline.
All system components must be installed in accordance with uk water regulations. if in any doubt a suitably qualified person should be consulted.
The SV93467 is used in the following Toilet Cisterns
- E600767 - Sottini Conceala 2 Cistern - Pneumatic Dual Flush Valve - top inlet Cistern - No Flushplate - 6 or 4.5 litre flush
- S362467 Conceala 2 Cistern - Top Inlet - Pneumatic Dual Flush Valve - No Flushplate - 6 or 4.5 litre flush
- S362567 - Conceala 2 Cistern - Bottom - Bottom Inlet - Pneumatic Dual Flush valve - No Flushplate - 6 or 4.5 litre flush
- S369867 - Conceala 2 CisternTi No Finish 6L Ul Dfv Venesta
- SV95767 - Concealed Cistern Pneumatic Dual Flush Valve
