Hansgrohe 95843000 Ecostat Comfort Handle Fixing Set

Summary

The Hansgrohe 95843000 handle fixing set is a replacement fixing component for selected Hansgrohe Ecostat Comfort thermostatic shower and bath mixer handles. It is used where the handle fixing parts are missing, damaged or no longer retaining the control handle correctly.

This part is for the handle-fixing area of the valve assembly. It does not replace the thermostatic cartridge, flow cartridge, diverter cartridge or non-return valve, so faults such as poor temperature control, weak flow, water passing when turned off or backflow should be checked against the relevant internal spare before ordering.

Technical Details

• Shown as position 3 on the 13113000, 13114000 and 13116000 Ecostat Comfort spare diagrams
• Shown as position 2 on the 13117000 Ecostat Comfort Care spare diagram

Confirmed Models

• Hansgrohe 13116000 Ecostat Shower Thermostat Comfort for Exposed Installation 09/11 - 06/12 Spare Parts
• Hansgrohe 13113000 Ecostat Shower Thermostat Comfort for Exposed Installation Hq >07/12 Spare Parts
• Hansgrohe Ecostat Comfort Exposed Thermostatic Bath Mixer 13114000 Spare Parts
• Hansgrohe 13117000 Ecostat Shower Thermostat Comfort Care for Exposed Installation with Extra Long Handles 04/12 - 06/12 Spare Parts

Before Ordering Check

• Match the model number and construction date on the valve or spare-parts diagram before ordering.
• Check whether the fault is with the handle fixing set or the complete handle before replacing this part.
• If the control handle is damaged as well as loose, the separate handle may also be required.

Troubleshooting Check

• Symptom: handle feels loose or will not stay securely in position.
• Likely cause: worn, missing or damaged handle-fixing components.
• Solution: replace the handle fixing set after confirming the exact Hansgrohe model and production date.
• If the fault is poor temperature regulation, stiff flow control, leakage or reverse flow, inspect the cartridge, shut-off unit or non-return valve instead.

Related Spares You May Need

• Hansgrohe 95836000 Handle
• Hansgrohe 98282000 Thermostatic Cartridge for Ecostat, Axor, Verostat, Croma and Raindance Shower Valves
• Hansgrohe 92373000 Thermostatic Cartridge - Reverse Supplies (30747400)
• Hansgrohe 94149000 1/2" On/Off Half Turn Ceramic Disc Cartridge (Anti-Clockwise Turn On)
• Non Return Valve (NRV) for Hansgrohe 96737000
• Hansgrohe 98283000 Axor Starck Diverter Cartridge Shut off Unit with Selector
