Dornbracht 09121200290 Spline Adapter

SUMMARY

Dornbracht 09121200290 is a white spline adapter / fixing cap used in selected Dornbracht handle, tap, wall valve, mixer and concealed shower control assemblies. It is used where the Dornbracht spare-parts breakdown specifies the adapter or fixing cap beneath the handle assembly.

This part helps locate the handle or control correctly onto the operating part below it, allowing the handle movement to transfer properly to the cartridge, upper part or valve spindle. It should be ordered by matching the part number shown in the spare-parts diagram rather than by size alone.

Part Number Cross Reference

- - Older Dornbracht code: 09121200290

- - Older spaced Dornbracht code: 09 12 12 002 90

- - Alternate listed part number: 09.12.12.002.90

- - Newer Dornbracht replacement code: 9012120020090

- - Newer spaced Dornbracht code: 90 12 12 002 00 90

- - Older diagrams showing 09 12 12 002 90 should be cross-referenced to the newer 90 12 12 002 00 90 service part.

- - Current diagrams showing 90 12 12 002 00 90 use the newer service code; old stock labelled 09121200290 or 09 12 12 002 90 is predecessor stock for the same fixing cap / spline adapter.

Technical Details

- - Brand: Dornbracht

- - Part type: spline adapter / fixing cap / upper-part adapter

- - Colour: white

- - Size reference found during research: 15 x 12 mm

- - Application: selected Dornbracht shower valve, tap, mixer, wall valve and concealed control handle assemblies

Confirmed Compatible Models

- - Dornbracht Tara Wall Valve Clockwise Closing 1/2 - Brushed Dark Platinum 36 607 892-99 Spare Parts

- - Dornbracht Tara Wall Valve Clockwise Closing 3/4 - Brushed Dark Platinum 36 608 892-99 Spare Parts

- - Dornbracht Tara Wall Valve Clockwise Closing 3/4 - Matte White 36 608 882-10 Spare Parts

- - Dornbracht Tara Concealed Two-Way Diverter - Platinum 36 200 892-08 Spare Parts

- - Dornbracht Tara Concealed Thermostat with Three Function Volume Control - Matte White 36 427 892-10 Spare Parts

- - Dornbracht Pivot Single Lever Mixer 33845875 99 Spare Parts

- - Dornbracht TARA Concealed Thermostat with Two-Way Volume Control 36 426 970-33 0010

- - Dornbracht META Concealed Thermostat with Two-Way Volume Control 36 426 970-00 0010

- - Dornbracht CL.1 Wall Valve Clockwise Closing 1/2 36 607 740-06

- - Dornbracht IMO Concealed Thermostat with Three Function Volume Control 36 427 670-08

Before You Order

- - Check the exact spare-parts diagram for your Dornbracht valve, tap, mixer or thermostat before ordering.

- - Match either the older code 09121200290 / 09 12 12 002 90 or the newer code 9012120020090 / 90 12 12 002 00 90 against your diagram.

- - Do not order from the 15 x 12 mm size reference alone because fitment depends on the specified Dornbracht assembly.

Related Spares You May Need

- - Dornbracht 9090031430090 Flow Cartridge Assembly - Anti-Clockwise Open

- - Dornbracht 9090031420090 Flow Cartridge Assembly - Clockwise Open (90 90 03 142 00 90)

- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
