Triton 83316190 Thermostatic Cartridge
SUMMARY
The Triton 83316190 thermostatic cartridge is a push-fit temperature control cartridge used in selected Triton bar mixer showers and Triton bar mixer showers with diverter. It is the internal cartridge that regulates mixed water temperature inside the shower valve.
This cartridge is suitable to check when the shower temperature is difficult to control, fluctuates, or no longer holds the commissioned outlet temperature. The flow control cartridge should be checked separately if the shower will not shut off.
Technical Details
- - Part Number: 83316190
- - Total length: 91.4mm including wax thermostat at bottom
- - Top spline diameter: 9.6mm
- - Top spline teeth / notches: 24
- - Diameter at Widest Point: 33.8mm
- - Diameter at top O-ring: 33.5mm
- - Diameter at middle O-ring: 31.8mm
- - Diameter at bottom O-ring: 30.1mm
- - Fitting type: push fit with M5 (5.7mm) grub screw
- - Grub screw is not included
Before Ordering
- - Remove the old cartridge and compare the total length, spline diameter, 24-tooth spline, O-ring positions and push-fit body before ordering.
- - Apply a suitable silicone grease to the cartridge O-rings during installation to help protect the seals and ease fitting.
Confirmed Compatible Models
- - Triton SFXLEVTHBMDIV Levano Chrome Bar Shower Mixer Spare Parts
- - Triton REPIRTHBMDIV Pirlo Bar Diverter Mixer Shower Spare Parts
- - Triton Muse Bar Mixer Shower with Diverter - January 2021 - Spare Parts - TR DV 378
- - Triton SWMELBMDIV Melita Bar Mixer Shower with Diverter Spare Parts
- - Triton Leona Bar Diverter Mixer Shower - November 2020 - Spare Parts - TR DV 342
- - Triton UNQUTHBM Quartier Bar Mixer Shower Spare Parts
- - Triton Muse Bar Mixer Shower With Diverter - Black - January 2021 - Spare Parts - TR DV 401
- - Triton Tian Bar Diverter Mixer Shower - October 2020 - Spare Parts - TR DV 356
- - Triton SWTIATHBMDIV Tian Bar Shower Mixer with Diverter Spare Parts
- - Triton Carnival Bar Mixer Shower with Diverter - May 2019 - Spare Parts - TR DV 375
- - Triton Benito Bar Diverter Mixer Shower - October 2020 - Spare Parts - TR DV 352
- - Triton UNDETHBMDIV Dene Bar Diverter Mixer Shower Spare Parts
- - Triton UNDETHBMDIVLE Dene Lever Bar Diverter Mixer Shower Spare Parts
- - Triton UNFITHBMDIV Fixate Bar Shower Mixer with Diverter Spare Parts
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- - Triton 83316690 Diverter Cartridge
