Stop Ring for Inta PU100003XX Thermostatic Cartridge
Send a photo of your item and we'll help confirm it.
Summary
Stop Ring for Inta PU100003XX Thermostatic Cartridge
The Inta PU100003XXSR is a temperature stop ring for the Inta PU100003XX thermostatic cartridge. It is used on the temperature-control side of selected Inta dual outlet thermostatic shower valves and is associated with setting the safe temperature stop after cartridge servicing or replacement.
The stop ring is fitted in the PU100003XX thermostatic cartridge assembly and is used during calibration of the mixed water temperature. Check the removed stop ring, cartridge code and valve model before ordering, especially where the valve also uses separate flow or diverter cartridges.
Technical Details
| Brand | Inta |
|---|---|
| Part Number | PU100003XXSR |
| Part type | temperature stop ring |
| Associated cartridge | PU100003XX thermostatic cartridge |
| Application | temperature-stop and calibration component for selected Inta dual outlet thermostatic shower valves |
- Do not order this part as a thermostatic cartridge, flow cartridge or diverter cartridge; it is the stop ring used with the PU100003XX cartridge assembly.
Confirmed Compatible Models
- Inta PU10032CP Puro Safe Touch Thermostatic Shower (Telescopic Riser)
- Inta PU10036CP Puro Deluxe Thermostatic Shower (Adjustable Riser)
- Inta KK10032CP Kiko Thermostatic Bar Shower with Telescopic Riser
- IN20016CP
Before Ordering
Check that the shower valve uses the PU100003XX thermostatic cartridge and that the required part is the temperature stop ring rather than the cartridge itself. If the shower has poor temperature control, unstable mixed water temperature or cannot be calibrated correctly, inspect the PU100003XX cartridge as well as the stop ring position. If water continues to drip from the shower head or outlet when the shower is turned off, check the flow cartridge, diverter cartridge and valve seals before assuming the stop ring is the cause.
Related Spares You May Need
- Inta PU100003XX Thermostatic Cartridge for Puro and Kiko Dual Outlet Shower Valves
- TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
- Inta PU100004XX Flow Cartridge
- Inta CB0003 Flow Cartridge Diverter for CB10010CP / PU10032CP
- Instinct Coll Duel Outlet Bar Thermostatic Cartridge IN20016CP Compatible Spare
