SK1400-2 Sirrus / ShowerForce Full TS1400 Thermostatic Cartridge Assembly (Gummers, NewTeam)

SUMMARY

Sirrus SK1400-2 Full TS1400 Thermostatic Cartridge Assembly Which is Used in Sirrus / Gummers, NewTeam, ShowerForce and Bristan Shower Valves.

Included
- 1 x SK1400-2 (New Generation) Cartridge
- 1 x Plastic shuttle piston
- 1 x Wax thermostat element (brass piece with rubber sleeve)
- Silicone Grease
- O-Rings, Spring, Circlip
- Handle Spindle Adapter (Slides onto the top spindle)

Not all of the above o rings and the spindle adapter will be needed in every replacement as this replacement has been manufactured with all the pieces required from all different variations an

This cartridge is used in the following models:
- Showerforce 970, 970T, SF 970-T
- Showerforce 971, 971T, SF 971-T
- Showerforce 972, 972T, SF 972-T
971 &972(Newteam) Shower Spares Sirrus Ts1400 Thermostatic Shower Valve Shower Spares

The SK1400-2 has been discontinued, but it is available on Di Vapor. This Gummers Sirrus, NewTeam, ShowerForce, and Bristan compatible cartridge assembly can be dispatched on the next working day if ordered before 3:00 PM, Monday to Friday.

Is your thermostatic cartridge no longer produced? You can opt to have it repaired. We offer a reconditioning service for discontinued thermostatic cartridges.

Frequently Asked Questions: Sirrus / ShowerForce SK1400-2 Thermostatic Cartridge Assembly
Q: What is the difference between the SK1400-1 and the SK1400-2?
A: SK1400-1 is the part number for the seal kit. SK1400-2 is for the cartridge.

Q: The shower is leaking. Do I have to replace the cartridge?
A: The problem might be caused by a faulty cartridge. If this is the case, it has to be replaced.

Installing the SK1400-2 Sirrus
This is the general process for replacing a shower or a bathtub valve (for a diagram of the installation, please see the image above):

1. Isolate the hot and cold water supply.
2. Remove the shower handle assembly and temperature stop ring.
3. Unscrew the cartridge. Make sure to remove the old cartridge assembly down to the spring.

4. Put together the new Sirrus cartridge assembly and slide it inside the shower valve.
5. Restore the temperature stop ring and the handle.
6. Open water supply lines and check if the cartridge installation is successful.

The SK1400-2 Sirrus is suitable for Showerforce and Newteam valves. The thermostatic cartridge delivers the preferred water temperature by mixing hot and cold water. The piston within the cartridge allows the valve to adjust the temperature. As the pressure fluctuates from one side of the supply line, it regulates the pressure from the other line to even out the temperature.
