Dornbracht 09304001090 Temperature Handle Carrier
Send a photo of your item and we'll help confirm it.
Summary
Dornbracht 09304001090 is a temperature handle carrier and regulator component used on selected Dornbracht wall-mounted thermostatic shower assemblies. It sits behind the temperature control handle and helps transfer handle movement to the thermostat control interface.
This is not the thermostatic cartridge itself. Use it when the temperature handle carrier or regulator interface is worn, damaged or no longer engaging correctly with the thermostat control assembly. If the shower temperature is unstable or difficult to control, inspect the thermostatic cartridge as well because the carrier and cartridge are separate service parts.
Technical Details
| Di Vapor part number | 09304001090 |
|---|---|
| Part type | temperature handle carrier / regulator |
| Application | temperature-control side of selected Dornbracht wall-mounted thermostatic shower valves |
- Related Dornbracht code forms found for the regulator position: 09 30 40 010 90; 90 30 40 010 00 90 new version; 9030400100090 new version
- No verified standalone dimensions were found for this part, so check the part code and full valve article number before ordering
Confirmed Compatible Models
- Dornbracht Series Specific Shower Thermostat for Wall-Mounted Installation Chrome 34 442 979-00
- Dornbracht Series Specific Shower Thermostat for Wall Mounting Brushed Platinum 34 442 979-06
- Dornbracht Series Specific Shower Thermostat for Wall Mounting Platinum 34 442 979-08
- Dornbracht Series Specific Shower Thermostat for Wall Mounting Brushed Durabrass 23kt Gold 34 442 979-28
- Dornbracht Series Specific Shower Thermostat for Wall Mounting Matte Black 34 442 979-33
- Dornbracht Series Specific Shower Thermostat for Wall Mounting Brushed Dark Platinum 34 442 979-99
Before You Order
Check the complete Dornbracht thermostat article number and the part code before ordering. Do not order this handle carrier by appearance alone, because similar Dornbracht thermostat handles, cartridges and regulator parts are used across different valve families.
