Grohe 24078000 Grohtherm Thermostatic Mixer 1 Outlet with Shut Off Valve Spare Parts
Send a photo of your item and we'll help confirm it.
Summary
Shower Spares for Grohe 24078000 Grohtherm Thermostatic Mixer 1 Outlet with Shut Off Valve
- Set for Final Installation for Grohe Rapido Smartbox 35 600/35 604
- Grohe Turbostat Compact Cartridge with Wax Thermoelement
Spare parts for the Grohe 24078000 Grohtherm concealed thermostatic shower mixer with one controlled outlet and a separate shut-off control. This chrome final-installation trim set is fitted over a Grohe Rapido SmartBox concealed rough-in body.
The thermostatic control maintains the selected mixed-water temperature through a Grohe TurboStat compact cartridge with a wax thermoelement. The separate control operates the water shut-off function. This page can be used to identify the correct handle, control cartridge and thermostatic cartridge for servicing the 24078000 mixer.
Technical Details
| Brand | Grohe |
|---|---|
| Range | Grohtherm |
| Category | Shower mixer |
| Product code | 24078000 |
| Mixer type | concealed thermostatic shower mixer |
| Number of controlled outlets | 1 |
| Control functions | temperature adjustment and water shut-off |
| Installation type | final-installation trim set for a concealed rough-in body |
| Required rough-in system | Grohe Rapido SmartBox 35 600 or 35 604 |
| Finish | chrome |
| Escutcheon material | metal |
| Escutcheon dimensions | 158 x 158 mm |
| Approximate total projection from the finished wall | 43 mm |
| Alignment adjustment | up to 6 degrees |
| Temperature safety stop | 38 C |
| Additional configurable temperature limit | 43 C or 46 C |
| Thermostatic system | Grohe TurboStat compact cartridge with wax thermoelement |
| Shut-off valve operation | ceramic valve with 120-degree operation |
| Internal protection | non-return valves and dirt strainers |
Confirmed Installation Systems
- Grohe 35600000 Rapido SmartBox Universal Rough-In Box 1/2
- Grohe 35604000 Rapido SmartBox Universal Rough-In Box 1/2
Before You Order Check
Confirm that the mixer code is 24078000 and check whether the installation uses Rapido SmartBox 35 600 or 35 604. Compare the code printed on the existing service component before ordering because several visually similar Grohe handles, Aquadimmer cartridges and thermostatic cartridges are available. The concealed SmartBox rough-in body is not included with the final-installation trim.
Grohe 49083000 Shut-Off Volume Control Handle for Grohtherm Thermostatic Shower ValvesThe Grohe 49083000 is a chrome shut-off and volume-control handle used on selected Grohtherm concealed thermostatic shower valve trims. It operates the flow control, allowing the user to turn th...
GROHE 49084000 AquaDimmer Flow Control and Diverter Cartridge for Thermostatic MixersNOTE: Please make sure that this is the correct Aquadimmer cartridge as there are a number of different diverter flow cartridges that have been used in the Aquadimmer range.The GROHE 49084000 is ...
Grohe 49028000 Thermostatic Cartridge for SmartControl with 3 valves (29121 000)The GROHE 49028000 is a 3/4 inch thermostatic compact cartridge used to regulate mixed-water temperature in a wide range of GROHE concealed thermostatic controls. This cartridge is also used in verifi...
