Vado GEO-109/VALVE/CD/HT Hot Flow Cartridge for Geo 3 Hole Basin Mixers
Send a photo of your item and we'll help confirm it.
Summary
Vado GEO-109/VALVE/CD/HT hot flow cartridge for Geo 3 hole basin mixer taps. This ceramic flow cartridge is used in the flow control side of compatible Vado Geo wall mounted basin mixer tap assemblies and provides quarter turn operation for smooth opening and shut-off.
What This Part Does
This cartridge controls water flow through one side of the tap. As the handle is turned, the internal ceramic discs open and close the waterway to regulate flow. Replacing a worn cartridge can restore proper shut-off and smoother handle operation.
Technical Information
| Part number | GEO-109/VALVE/CD/HT |
|---|---|
| Type | ceramic flow cartridge |
| Application | basin mixer tap |
| Turn | quarter turn 90 degree operation |
| Close direction | anti-clockwise close / clockwise open |
| Overall length including bottom seal | approximately 56.6mm |
| Diameter at widest threaded point | approximately 23.8mm |
| Top spline diameter | approximately 7.5mm |
| Spline count | 20 teeth |
| Lower thread diameter | approximately 20.6mm |
| Barrel diameter below lower thread | approximately 18.5mm |
| Bottom seal colour | red |
Common Symptoms of Failure
- Dripping from the tap outlet when the tap is turned off indicating the cartridge needs replacing
- Stiff or rough handle movement
- Difficulty fully opening or shutting off the water flow
- Wear affecting smooth quarter turn operation
Confirmed Compatible Models
- Vado GEO-109-C/P Geo wall mounted 3 hole basin mixer
- Vado GEO-109-220-C/P Geo 3 Hole Basin Mixer with 220mm Spout
Important Notes
- This listing is for the flow cartridge only
- Always match the full part number GEO-109/VALVE/CD/HT before ordering
- Check the original cartridge dimensions spline count and rotation direction against your existing part before purchase
