Trevi A962568NU Ceratherm Diverter (Ideal Standard)
SUMMARY
Ideal Standard Trevi A962568NU Ceratherm Bath and Shower Flow Diverter Cartridge
The Ideal Standard Trevi A962568NU is a combined flow-control and diverter cartridge used in selected Ceratherm, Idealrain, Alto Ecotherm, CeraPlus 2, Idealjet and Jado Neon thermostatic bath and shower assemblies.
This cartridge controls water shut-off and switches the mixed water supply between outlets, such as a bath spout and shower handset or an overhead shower and handset. Water temperature is regulated by a separate thermostatic cartridge.
Technical Details
- - Part Number: A962568NU
- - Alternative manufacturer reference: A 962 568 NU
- - Part type: combined flow-control and diverter cartridge
- - Function: water shut-off and outlet selection
- - Material: metal
- - Finish designation: NU - Neutral
- - Net weight: 0.1 kg
Confirmed Compatible Models
The following Ideal Standard, Trevi and Jado bath and shower assemblies are documented as using A962568NU. Where different production generations exist, check the original valve assembly before ordering.
- - Ideal Standard A4623AA Ceratherm 100 exposed thermostatic bath/shower mixer - from April 2010
- - Ideal Standard A4624AA Ceratherm 100 thermostatic bath/shower mixer with shower kit
- - Ideal Standard A4630AA Ceratherm 200 thermostatic bath/shower mixer - GEN1 assembly
- - Ideal Standard A4630AA Ceratherm 200 thermostatic bath/shower mixer - from May 2010
- - Ideal Standard A4639AA Ceratherm exposed shower thermostat with upper and lower outlets - from July 2010
- - Ideal Standard A4815AA Ceratherm 100 deck-mounted thermostatic bath/shower mixer - GEN1 assembly
- - Ideal Standard A4815AA Ceratherm 100 deck-mounted thermostatic bath/shower mixer - from July 2010
- - Ideal Standard A4816AA Ceratherm 100 bath-rim thermostatic mixer with shower kit - from July 2010
- - Ideal Standard A4818AA Ceratherm 200 thermostatic bath/shower mixer with shower kit - from May 2010
- - Jado A5576AA Neon exposed thermostatic bath/shower mixer - from September 2010
- - Ideal Standard A5686AA Ceratherm 100 with dual shower kit - October 2010 to February 2018 assembly
- - Ideal Standard A5686AA Ceratherm 100 with dual shower kit - February 2018 assembly
- - Ideal Standard A5686AA Ceratherm 100 dual shower system - general spare parts
- - Ideal Standard A5778AA Ceratherm 100 thermostatic bath/shower mixer with dual shower kit - from August 2011
- - Ideal Standard A5827AA Ceratherm 100 dual exposed thermostatic shower - March 2013 to January 2018 and February 2018 assemblies
- - Ideal Standard A5833AA Idealrain Cube M3 thermostatic shower system - February 2018 assembly
- - Ideal Standard A6037AA Idealrain Eco / Idealrain S thermostatic shower system - from December 2012
- - Ideal Standard A6142AA Alto Ecotherm bar shower with rigid riser - original September 2013 assembly
- - Ideal Standard A6142AA Alto Ecotherm bar shower with rigid riser - shower spare parts
- - Ideal Standard A6142AA Alto Ecotherm rigid-riser shower - IDL DV 382 assembly
- - Ideal Standard A6246AA Idealrain Luxe thermostatic shower system
- - Ideal Standard A6247AA Idealrain Cube Luxe thermostatic shower system
- - Ideal Standard A6272AA Ceratherm 100 / Idealrain thermostatic shower system - March 2014 to March 2018 and April 2018 assemblies
- - Ideal Standard A6290AA Ceratherm 100 shower valve - GEN1 assembly - October 2016 to June 2023 versions only
- - Ideal Standard A6290AA Ceratherm 100 Freedom shower pack - October 2016 to June 2023 versions only
- - Ideal Standard A6426AA Ceratherm 25 exposed thermostatic bath/shower system - from November 2015
- - Ideal Standard A6874AA CeraPlus 2 thermostatic bath/shower mixer with standard S-connectors - April 2017 to March 2021 assembly
- - Ideal Standard A6942AA Idealjet / Ceratherm 100 New thermostatic shower system - from January 2018
- - Ideal Standard A6984AA Idealrain Luxe shower system with Ceratherm 100 and EvoJet - from June 2018
- - Ideal Standard A6986AA Idealrain Luxe shower system with Ceratherm 100 and EvoJet Diamond - from July 2018
- - Ideal Standard A6987AA Ceratherm 100 Evo Round thermostatic shower system - from July 2018
- - Ideal Standard A6988AA Ceratherm 100 Evo thermostatic shower system - from July 2018
- - Ideal Standard F1696AA Ceratherm 100 exposed thermostatic bath/shower mixer - March 2015 to September 2021 and September 2021 assemblies
- - Ideal Standard F1738AA Idealrain Luxe thermostatic shower system - October 2016 to February 2018 and February 2018 assemblies
Important A6290AA Production Change
A962568NU is specified for the A6290AA assemblies manufactured from October 2016 to June 2023. The assembly introduced in June 2023 uses A861774NU with A861776NU retaining and stop-ring components instead. These cartridges must not be assumed to be interchangeable. Identify the installed valve assembly before ordering, particularly for units manufactured around June 2023.
Common Fault Symptoms
- - Water continues dripping from the shower head or bath spout when the mixer is turned off
- - Water does not shut off fully when the flow control is closed
- - The diverter becomes difficult to operate or fails to select the intended outlet
- - Water does not flow correctly to the selected shower outlet
These symptoms can indicate wear, damage or an obstruction affecting the flow-control and diverter mechanism. Check the cartridge, seals, seating and connected components before replacing parts.
Installation and Before Ordering Checks
Isolate both water supplies and release pressure before removing the existing cartridge. Check the model-specific installation instructions and note the orientation of the existing cartridge before dismantling the assembly.
- - Check the exact valve or shower model number
- - Compare the original cartridge and its locating features with A962568NU
- - Check the spindle, retaining nut and any separate handle carrier or extension
- - Inspect the seals and cartridge seating for wear, damage or debris
- - Confirm the correct assembly generation if the shower model has been revised
For the A4815AA assembly, the installation instructions specify a 30mm across-flats spanner for the diverter retaining nut. The cartridge must be installed with its locating peg at the top and the spindle arranged so that the right-hand port is closed. This orientation instruction relates specifically to A4815AA and should not be assumed for other models.
After installation, restore the supplies and check that water shuts off fully, the diverter selects the correct outlet and no leaks are present.
Related Spares You May Need
The following parts are associated with individual models and production versions listed above. Not every component is used in every valve. Check the relevant model's spare-parts page before ordering. Separate thermostatic cartridges and bath-spout diverters are not substitutes for A962568NU.
Control Handles and Cartridges
- - A860780AA Separate bath-spout diverter - A5778AA
- - A861007AA Ceratherm 60 diverter handle - A6942AA
- - A861195AA Temperature-control handle with ISI logo - A6873AA and A6874AA
- - A861198AA Complete volume-control handle - A6873AA and A6874AA
- - A861296AA Complete volume-control handle
- - A960801AA Chrome volume-control handle - F1738AA
- - A961095NU Temperature-control handle screw
- - A961889NU Temperature-adjustment unit - F1738AA
- - A962229NU Ecotherm thermostatic cartridge
- - A962232AA Alto Ecotherm temperature-control handle - A6037AA, A6142AA and A6942AA
- - A962233AA Alto Ecotherm volume-control handle - A6037AA and A6142AA
- - A962870AA Chrome temperature-control handle
- - A962871AA Chrome volume-control handle
- - A962872AA Ceratherm handle cap
- - A962878AA Ceratherm 200 handle cap - A4630AA, A4818AA and A5576AA
- - A962879AA Ceratherm 200 temperature-control handle - A4630AA and A4818AA
- - A962880AA Ceratherm 200 volume-control handle - A4630AA, A4818AA and A5576AA
- - A963427NU Temperature carrier and handle extension
- - A963432NU Volume-control handle carrier
- - B960167AA Separate automatic bath-spout diverter - A6426AA
- - B960486AA Bath-spout diverter pull knob - A6426AA
- - F961044NU Exposed-shower thermostatic cartridge - F1738AA
- - F961115AA Complete volume-control handle - A6290AA
- - F961116AA Temperature-control handle with ISI logo - A6290AA
Seals, Connectors and Installation Fittings
- - A860321NU O-ring - A4630AA, A4818AA and A5576AA
- - A860933NU O-ring
- - A861197NU Isolation-ring set - A6873AA and A6874AA
- - A960071NU O-ring - A4630AA, A4818AA and A5576AA
- - A960196NU Stream-regulator key
- - A960395NU Cache TT flow straightener
- - A960537AA Spout end - A6426AA
- - A960599AA Outer escutcheon - A6873AA and A6874AA
- - A960914AA Chrome escutcheon - A6037AA, A6426AA and A6942AA
- - A960942NU Pair of O-rings - A6246AA and A6272AA
- - A961332NU Two-piece O-ring set
- - A961337NU M4 set screw - A6873AA and A6874AA
- - A962050AA Complete S-connector - A6874AA
- - A962149AA Screw with chrome cap - A6873AA and A6874AA
- - A962218NU O-ring kit with A962605NU - A4630AA, A4818AA and A5576AA
- - A962230NU O-rings and screens for A962229NU thermostatic cartridge
- - A962569NU Pair of complete S-connectors - A4630AA, A4818AA and A5576AA
- - A962594NU Non-return valve pack
- - A962605NU O-ring - A6426AA
- - A962857NU M6 x 10 grub screw - A4630AA, A4818AA and A5576AA
- - A962998NU Pair of M4 screws
- - A963299NU O-ring
- - A963469NU O-ring - A6246AA and A6272AA
- - A963490AA Connecting set with noise reducer - A6426AA
- - A963838AA Inner escutcheon - A6874AA
- - B950422AA Complete deck elbow - A4815AA and A4816AA
- - B960242AA Concept 100 escutcheon
- - B960575AA Escutcheon set for on/off S-connectors - A6873AA
- - F961082AA M24 aerator - A6873AA and A6874AA
Shower System Parts and Maintenance
- - A860873AA Idealrain shower-bar extension
- - A861117AA Slider and handset holder for 25mm bar - A6290AA and F1738AA
- - A861142AA 745mm shower rail - F1738AA
- - A861143AA 835mm shower rail
- - A861144AA 993mm shower rail
- - A861146AA 1354mm shower rail - A6426AA and F1738AA
- - A861273AA 250mm headshower - A6942AA
- - B0024AA Idealrain Cube M1 200mm rainshower - A5833AA and A6988AA
- - B1364AA Hose-retaining ring - A6290AA, A6987AA and A6988AA
- - B1759AA Idealrain EvoJet Round three-function handset - A6984AA
- - B1760AA Idealrain EvoJet Diamond three-function handset - A6986AA
- - B2231AA Idealrain Evo Round three-function handset - A6942AA and A6987AA
- - B2232AA Idealrain Evo Diamond three-function handset - A6988AA
- - B9401AA Idealrain S3 three-function handset - A6037AA, A6142AA and A6426AA
- - B9403AA Idealrain M3 shower handset
- - B9442AA Idealrain M1 200mm rainshower
- - F960891AA Shower-bar wall holder
- - F961141AA 993mm shower rail - A6290AA
- - F961146AA Rigid U-shaped tube elbow
- - TAC86 TACSIL silicone grease 3g - for suitable cartridge seal maintenance
If you are unsure which part you need, use the Di Vapor part identification service and we will help you find the right spare.
