Grohe 23054003 Eurodisc Cosmopolitan Single-Lever Basin Mixer (1/​2 Inch) L-Size Spare Parts

SUMMARY

Spare parts for the Grohe 23054003 Eurodisc Cosmopolitan single-lever basin mixer, a chrome L-Size basin tap with a swivel tubular spout, mechanically operated pop-up waste and single-lever control of water flow and temperature.

The mixer uses a 35mm GROHE SilkMove ceramic cartridge. Wear within the cartridge can cause stiff or inconsistent lever operation, difficulty controlling the mixed-water flow or temperature, or water continuing to drip from the spout after the tap has been turned off. The verified Grohe spares listed below include the main cartridge, waste operating rods and the manufacturer-listed service socket spanner.

Technical Details

- - Brand: GROHE

- - Range: Eurodisc Cosmopolitan

- - Category: Basin mixer

- - Product code: 23054003

- - Product type: Single-lever basin mixer 1/2 Inch L-Size

- - Finish: Chrome

- - Cartridge: GROHE SilkMove 35mm ceramic cartridge

- - Flow control: Adjustable flow-rate limiter

- - Installation system: FastFixation Plus

- - Spout type: Swivel tubular spout

- - Adjustable swivel area: 0 degrees, 150 degrees or 360 degrees

- - Waste: Pop-up waste set, 1 1/4 inch

- - Water connections: Flexible connection hoses

- - Overall mixer height: 291mm

- - Spout outlet height: 263mm

- - Spout projection: 143mm

- - Mixer body diameter: 48mm

- - Installation hole diameter: 34mm

- - Maximum mounting surface thickness: 30mm

- - Flexible hose connection: G 3/8

- - Waste connection: G 1 1/4

- - Waste flange diameter: 63mm

- - EAN: 4005176472596

Before You Order

Check that the basin mixer model code is 23054003 before ordering spare parts. The similarly named 23054002 is a separate Eurodisc Cosmopolitan model code and should not be assumed to use the same component set solely because the product names are similar.
