Vernet TMV2 Thermostatic Shower Cartridge Replacement CAWH08-05
Send a photo of your item and we'll help confirm it.
Summary
This Vernet thermostatic cartridge has 24 teeth on its brass spline and 60 teeth on the plastic spline which the temperature control stop connects to.
We deliver worldwide for this replacement thermostatic cartridge. Di Vapor is the official spares partner for Vernet for all their cartridges, elements and products.
The CAWH08-05 is used on the following brands and models (however not restricted to these):
- VADO VEL-149/RRKSQ/DIV-C/P
- Vado Thermostatic cartridge retro-fit - VEL-RETROFIT/E2
- V-001A-PLA
The CAWH08-05 is part of the CA77 range of Vernet thermostatic shower cartridges. It is TMV2 standard approved for low pressure systems. The CAWH range is so sensitive it has even been approved for use with the NHS in the UK.
Please be sure to read our guide on how to identify which Vernet Thermostatic Cartridge you have, and please contact us if you are unsure which cartridge you require which will ensure you receive the correct cartridge first time to get you up and running.
THE CAWH QUALITY and CERTIFICATIONS
Each cartridge is individually checked for stability, flow, operating torque, leakage and anti-scald
function.
- France (NF 077)
- British Standards (EN 1111)
- American Society of Safety Engineers (ASSE 1016)
- American Society of Safety Engineers (ASSE 1070)
- American Society of Safety Engineers (ASSE 1017)
- National Health Service (NHS D08)
The CAWH: a high performance thermostatic cartridge that incorporates an innovative fixing system. This enables long product life and efficiency in all application:
- facilitate easy assembling,
- dimensioned for simple and cost-efficient faucet conception,
- lateral fixing system withstands water-hammer effects,
- resist up to 35 bar (508 psi) under static pressures,
- ensure the steadiest mixed outlet water temperature,
- compensate for changes in supply pressure and supply temperature,
- made from high quality polymer that resist scale build-up,
- patented design..
THE CAWH77 TEMPERATURE CONTROL
The CAWH77: a world-class solution for outstanding temperature control in compact package:
- temperature range from 15°C (59°F) to 60°C (140°F),
- factory preset at 38°C (100.4°F),
- high resolution within the comfort zone of 34°C to 42°C ( 93.2°F to 107.6°F),
- can be tailored to meet variety of application: 50°C (122°F) limitation, disinfection at 70°C (158°F).
- shut the water flow upon cold water supply failure
