Ultramix Trubert Eurotherm TX537 Thermostatic Cartridge (TX95E37, TX95C37)

SUMMARY

Ultramix Trubert Eurotherm TX537 Thermostatic Cartridge (TX95E37, TX95C37) - Flow Rate (Litres Per Minute): Minimum 5 - Maximum 260

The Ultramix Trubert Eurotherm TX537 is a replacement thermostatic cartridge for selected Watts ULTRAMIX TX95 high productivity thermostatic mixing valves using the 30 to 70 C cartridge specification. The Di Vapor part number is ET-TX537 and the manufacturer reference identified for this cartridge is 22TX537.

This thermostatic mechanism controls mixed water temperature inside the valve and is used where stable blended-water output is required across high-flow communal or multi-outlet installations. It is the 30 to 70 C version and should not be confused with the TX5 10 to 50 C cartridge used in other TX95 valve versions.

Technical Details

- - Part type: thermostatic cartridge / replacement thermostatic mechanism

- - Di Vapor Part Number: ET-TX537

- - Manufacturer reference: 22TX537

- - Cartridge setting range: 30 to 70 C

- - Valve family: Watts ULTRAMIX TX95 high productivity thermostatic mixing valves

- - Associated valve connection size: M 1 1/2 / 40x49 on TX95E37 and TX95C37 valve versions

- - Associated valve capacity: 1 to 32 points of use

- - Flow range for the current Watts TX95E37 / TX95C37 data is listed as 8-260 litres per minute; check the valve data plate and operating requirements before ordering where minimum flow is critical

- - Listed cartridge materials include brass, stainless steel, EPDM and covered steel

- - The TX95 valve design uses hot inlet on the left and cold inlet on the right unless a reverse-inlet version has been specified

Confirmed Compatible Models

- - Watts ULTRAMIX TX95E37

- - Watts ULTRAMIX TX95C37

- - Watts ULTRAMIX T/X95CHP 30 to 70 C cartridge version

Before Ordering

Check that the existing valve is a TX95E37, TX95C37 or the 30 to 70 C T/X95CHP version before ordering TX537. Do not order this cartridge for a standard TX95E or TX95C 10 to 50 C valve unless the valve documentation or data plate confirms the 30 to 70 C cartridge requirement.

Common Fault Symptoms

- - Symptom: unstable mixed water temperature

- - Likely Cause: worn or contaminated thermostatic mechanism

- - Solution: isolate the valve, inspect serviceable filters and check whether TX537 is the correct cartridge for the installed TX95 valve version

- - Symptom: valve will not maintain the selected outlet temperature

- - Likely Cause: failed thermostatic control element or internal cartridge wear

- - Solution: replace the thermostatic cartridge after confirming the valve code and cartridge temperature range

Related Spares You May Need

- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
