Ultra SBARCA02 Thermostatic Cartridge (Plastic Screw Fit)

SUMMARY

Ultra SBARCA02 Plastic Screw-In Thermostatic Cartridge for Bath Shower Mixers

Ultra SBARCA02 is a plastic-bodied, screw-in thermostatic cartridge for the temperature-control assembly of selected Ultra bath and shower mixers. It is used in the Reef CD324 mixer when fitted with the SBARCA02 cartridge version.

The cartridge regulates the hot and cold water mix to maintain the selected outlet temperature. It controls temperature rather than the separate on/off flow function, so a dripping outlet alone does not identify this cartridge as the faulty component.

Technical Details

- - Part code: SBARCA02

- - Part Number: SBARCA02

- - Part type: thermostatic temperature-control cartridge

- - Body material: plastic

- - Fitting method: threaded screw-in fitting

- - Application: bath and shower mixer temperature control

Confirmed Models Using This Cartridge

NOTE: The CD324 mixer has been listed with SBARCA01, SBARCA02 and SBARCA04 thermostatic cartridges. Check the cartridge already fitted, including its fixing method, body shape, thread, spindle and seal positions. Do not assume these part codes are interchangeable or select a cartridge from the mixer name alone.

- - Ultra / Hudson Reed Reef CD324 thermostatic bath and shower mixer - SBARCA02 cartridge version

Related Spares You May Need

For CD324 flow-control repairs, compare the original valve with the following spare before ordering. This is a separate component and does not replace SBARCA02.

- - Ultra SPR02 1/2 inch hot and cold ceramic disc cartridges - pair with 20 splines

Fitting Note

Isolate both hot and cold water supplies before removing the cartridge. Follow the mixer manufacturer's servicing instructions and check for leaks and correct temperature control after reassembly.

For help identifying the right cartridge, use the Di Vapor part identification service.
