GROHE 47025000 Grohe Grohmix Thermostatic Cartridge for THM 34952 Thermostat 3/4 (34411) Mixer Valves
Send a photo of your item and we'll help confirm it.
Summary
Grohe 47025000 Grohmix 3/4 Inch Wax Thermostatic Cartridge for 34411 and 34952
Grohe 47025000 is a 3/4-inch wax thermostatic cartridge used to regulate mixed-water temperature in selected Grohmix thermostatic shower and bath mixer valves. The thermo-element responds to changes in the hot and cold water supplies to maintain the selected outlet temperature.
This is the standard non-splined Grohmix cartridge configuration. Before ordering, compare the existing cartridge carefully, as Grohe also produced different Grohmix thermo-elements for other valve configurations, including splined and reverse-supply versions.
Technical Details
| Part Number | 47025000 |
|---|---|
| Part type | Wax thermostatic cartridge / thermo-element |
| Manufacturer designation | 3/4 inch |
| Construction | Brass |
| Fitting type | Screw-in |
| Overall length | approximately 128 mm |
| Widest diameter | approximately 50 mm |
| Main barrel diameter | approximately 42 mm |
| Configuration | Non-splined |
Function and Fault Diagnosis
A worn or faulty thermostatic cartridge can cause unstable mixed-water temperature, temperature drift, difficulty reaching the selected temperature, restricted temperature adjustment or slow response to changing water conditions. Dripping from the shower head when the valve is switched off is not normally a primary indication of failure of this thermo-element, because the cartridge regulates temperature rather than providing the main flow shut-off function.
Confirmed Compatible Models
- Grohe 34411000 Grohmix Shower
- Grohe 34411Z Grohmix
- Grohe 34411G Grohmix
- Grohe 34414 Grohmix
- Grohe 34952 Concealed Body for THM Thermostat Mixer 3/4 Inch
- Grohe 34428 000 Grohmix Thermostat Bath Mixer
Before You Order
Check the valve model, existing cartridge shape and supply arrangement before ordering Grohe spare parts. The Grohe 47024000 Grohmix Thermostatic Cartridge is a different splined configuration, while the Grohe 47032000 Grohmix Thermostatic Cartridge is intended for reverse hot and cold supply arrangements. Do not identify the required cartridge from dimensions alone.
