F960902NU Ideal Standard / Trevi Alto Ev Thermosatic Cartridge
Send a photo of your item and we'll help confirm it.
Summary
Ideal Standard Trevi F960902NU Alto EV Thermostatic Cartridge for A5985AA and A6101AA
Ideal Standard / Trevi F960902NU is a screw-in thermostatic cartridge used in Alto EV exposed thermostatic shower mixers. The cartridge controls the blend of hot and cold water helping to regulate and maintain the selected shower temperature.
Manufacturer spare-parts data lists the cartridge as F 960 902 NU and specifies it for both the September 2012 to April 2019 Alto EV assembly, and the revised assembly produced from May 2019. F960902NU remains the specified thermostatic cartridge across both production revisions.
Technical Details
| Part Number | F960902NU |
|---|---|
| Manufacturer code format | F 960 902 NU |
| Part type | screw-in thermostatic shower cartridge |
| Function | controls the hot and cold water mix to regulate the outlet temperature |
- Manufacturer service instructions specify a 24 mm A/F spanner for cartridge removal
- The Alto EV valve uses a 40 degrees C temperature safety stop and the temperature control should be recalibrated after cartridge replacement
- Before replacing the cartridge, check the valve filters and cartridge filter screens for blockage and clean them where required
- Suitable silicone grease should be applied to the cartridge O-rings during installation
- Common signs of a thermostatic cartridge problem can include unstable outlet temperature, poor response to temperature adjustment, or water running consistently too hot or too cold
- The earlier September 2012 to April 2019 Alto EV assembly uses A961214NU as the flow headwork while the manufacturer diagram for valves produced from May 2019 specifies B964931NU
- Current associated carrier codes are A963427NU for the temperature adjustment carrier and A963432NU for the volume control handle carrier. Older spare listings may show A953957NU11 and A923348 for these functions
Confirmed Compatible Models
- Ideal Standard A5985AA Alto EV exposed thermostatic shower mixer with 1 function shower kit
- Ideal Standard A6101AA Alto EV exposed thermostatic shower mixer
Before You Order
- Check the shower model code where possible because thermostatic cartridges are model-specific and should not be selected from appearance alone
- If the valve has poor temperature control, first check the inlet filters and cartridge screens for debris or scale before replacing the cartridge
Not sure this is the right cartridge? Use the Di Vapor Part Identification Service, and send a photo of your part.
Related Spares You May Need
- Ideal Standard A962361LJ handle cap grey
- Ideal Standard / Trevi A962998NU M4 handle fixing screws pair
- Ideal Standard A960834AA temperature handle chrome
- Trevi A963427NU temperature adjustment carrier and handle extension
- Ideal Standard A963432NU volume control handle carrier assembly
- Ideal Standard A961214NU 1/2 inch rubber valve internal headwork - September 2012 to April 2019 Alto EV
- Ideal Standard A961810NU seal kit
- Ideal Standard B960242AA escutcheon chrome
- Ideal Standard B961042AA wall fix kit
- Ideal Standard A963651NU 1/2 inch outlet nipple
- TACSIL 3g Premium Cartridge Silicone Grease
