Aqualisa 518101 Midas Thermostatic Cartridge (No Handle)
SUMMARY
Aqualisa 518101 is the thermostatic cartridge used in Midas 100 high pressure mixer valves. This listing is for the cartridge only and does not include the temperature control handle.
This cartridge controls mixed water temperature inside the valve. When the original cartridge is worn, scaled or sticking, common symptoms can include unstable temperature, poor hot water control, or a temperature knob that no longer sets the shower correctly.
Technical Details
- - Part number shown for this cartridge: AQUALISA-518101-CART
- - Total length: 91.4mm including the wax thermostat at the bottom
- - Diameter at widest point: 33.8mm
- - Top spline diameter: 9.6mm
- - Top spline teeth/notches: 24
- - Diameter at Middle O'ring: 31.8mm
- - Diameter at Bottom O'ring: 30.1mm
- - Fitting Type: Push Fit with M5 (5.7mm) Grub Screw (Grub Screw Not Included)
- - Check that your existing cartridge matches these measurements and that you need the no-handle version before ordering
- - If you need the version supplied with the temperature control knob, see Aqualisa Midas 100 Cartridge Including Temperature Control Handle
Confirmed Compatible Models
- - Aqualisa MD100BAR Midas 100 Bar Mixer Shower
- - Aqualisa MD100BSM Midas 100 Bath Shower Mixer
Related Spares You May Need
- - Aqualisa Midas 100 Cartridge Including Temperature Control Handle
- - Aqualisa 518103 Temperature Control Handle
- - Aqualisa Stop Ring for 518103 / 518101 Handle
- - Aqualisa 518102 MIDAS 100 FLOW CONTROL SERVICE KIT (INC KNOB) - 700579
