A963068AA Ideal Standard /​ Trevi THERM 300 Thermostatic Cartridge

Summary

A963068AA Ideal Standard / Trevi THERM 300 Thermostatic Cartridge

This thermostatic cartridge is used in the following shower valves:

• Trevi Therm 300 Built-in Thermostatic Shower Mixer
• Trevi Therm 310 Exposed Thermostatic Shower Mixer

Ideal Standard / Trevi A963068AA thermostatic cartridge for Trevi Therm 300 built-in and Trevi Therm 310 exposed thermostatic shower mixers.

This cartridge regulates the mixed water temperature inside the shower valve. It serves a different function from the separate flow cartridges and operating gears that control water flow and shut-off.

Technical Details

Check Before Ordering

Check the complete cartridge reference and the exact shower version before ordering. Do not assume that A963068AA and A963068NU are interchangeable. The Trevi Therm range includes different valve generations, so the range name or a partial cartridge measurement alone is not sufficient to identify the correct part.

Original MK1 temperature control handles have four flat sides, whereas MK2 temperature handles have two. Handles may have been changed during previous repairs, so use this only as an identification aid and check the original cartridge and valve arrangement as well.

Checking the Fault

Damaged or jammed operating gears can prevent the separate flow cartridges from opening or closing fully, affecting both flow and temperature regulation. Inspect these components when diagnosing the fault rather than assuming that every temperature problem requires a new thermostatic cartridge.

If water continues dripping from the shower head when the shower is turned off, inspect the on/off flow cartridges and their operating mechanism. The thermostatic cartridge controls temperature and should not be selected solely to resolve a shut-off fault.

Installation Note

Isolate both hot and cold water supplies before dismantling the shower valve. Follow the shower manufacturer's servicing instructions and, after reassembly, check for leaks and verify the outlet temperature before use.

Related Spares You May Need

These parts serve separate repair functions on the associated shower valves. Select only the items required for the fault and the version fitted.

• Trevi A952501NU on/off flow cartridge - sold individually; the valve uses two flow cartridges
• Trevi A963067NU gearbox cog and spindle assembly - confirm the shower revision and original spindle specification before ordering; do not select this assembly for an earlier valve requiring the shorter spindle
• Trevi A907294LJ T-logo temperature handle cap
• Trevi A962585NU black volume control handle cap
• Trevi A918416 temperature control handle fixing screw
• Trevi E918322NU M4 x 9.5mm volume handle fixing screw
• Trevi A962586AA chrome volume control handle
• Ideal Standard A922539NU11 volume handle carrier
• Ideal Standard A918434AA M4 x 50 chrome cover screw - aftermarket spare
• Trevi A953154AA11 chrome faceplate for the MK1 built-in 300 - discontinued reference
• TAC86 TACSIL 3g cartridge silicone grease - for cartridge O-ring lubrication during servicing

Associated Trevi Therm 310 Shower Kit Accessories

Check the existing shower kit before choosing a handset, slider or hose. These accessories are separate from the thermostatic cartridge repair.

• Ideal Standard B9400AA Idealrain S1 80mm single-function chrome handset
• Ideal Standard B9403AA IdealRain M3 handspray shower head
• Ideal Standard B960976AA Low Basic / I-RAIN 72 slider set
• Ideal Standard E4745AA Trevi 135cm chrome easyclean shower hose with 1/2 inch BSP connections

Use the Di Vapor part identification service if you need help finding the right part.
